Official File parts/15435.dat
Part Attributes:
File Header:
0 ~Minifig Helmet Large Square - Top
0 Name: 15435.dat
0 Author: Magnus Forsberg [MagFors]
0 !LDRAW_ORG Part UPDATE 2024-03
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2024-04-28 [OrionP] Official Update 2024-03
Show contents
