Unofficial File parts/69205.dat
Part Attributes:
File Header:
0 Tile 2 x 4 Mario with One Bottom Stud
0 Name: 69205.dat
0 Author: Magnus Forsberg [MagFors]
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2024-05-22 [MagFors] Using a subfile
0 !HISTORY 2025-02-01 {LEGO Instructions App} Original part shape
0 !HISTORY 2025-02-16 [MagFors] File preparation for LDraw Parts Tracker
0 !HISTORY 2025-02-16 [MagFors] Complete rework
Show contents
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\69205s01.dat
4 16 19.75 0 36.26 17.25 0 36.26 17.25 0 13.31 19.75 0 13.31
4 16 6.06 0 33.76 17.25 0 13.31 17.25 0 36.26 8.56 0 36.26
4 16 8.56 0 36.26 17.25 0 36.26 17.25 0 38.76 8.56 0 38.76
3 16 6.06 0 33.76 8.56 0 36.26 6.06 0 36.26
4 16 -5.5 0 33.76 -5.5 0 31.26 17.25 0 13.31 6.06 0 33.76
4 16 17.25 0 13.31 -5.5 0 31.26 -9.75 0 31.26 -9.75 0 28.76
3 16 -12.21 0 22 -12.25 0 8.5 17.25 0 13.31
4 16 17.25 0 13.31 -9.75 0 28.76 -12.21 0 28.76 -12.21 0 22
4 16 -14.75 0 22 -14.75 0 14.94 -12.25 0 8.5 -12.21 0 22
4 16 -12.25 0 8.5 -14.75 0 14.94 -17.25 0 14.94 -17.25 0 8.5
4 16 -12.25 0 8.5 14.75 0 4 17.25 0 4 17.25 0 13.31
4 16 12.25 0 -1 14.75 0 4 -12.25 0 8.5 -12.25 0 5.78
3 16 14.75 0 -1 14.75 0 4 12.25 0 -1
3 16 -17.25 0 5.78 -17.25 0 3.28 -12.25 0 5.78
4 16 -12.25 0 5.78 -17.25 0 3.28 -17.25 0 -15.08 12.25 0 -1
4 16 -17.25 0 3.28 -19.75 0 3.28 -19.75 0 -15.08 -17.25 0 -15.08
4 16 12.25 0 -1 -17.25 0 -15.08 -12.75 0 -17.58 12.25 0 -13.5
3 16 -17.25 0 -17.58 -12.75 0 -17.58 -17.25 0 -15.08
4 16 12.25 0 -13.5 -12.75 0 -17.58 .75 0 -26.85 3.75 0 -26.85
3 16 .75 0 -26.85 -12.75 0 -17.58 -12.75 0 -20.14
4 16 .75 0 -26.85 -12.75 0 -20.14 -1.75 0 -31.25 .75 0 -31.25
4 16 -19.75 0 -20.14 -1.75 0 -33.75 -1.75 0 -31.25 -12.75 0 -20.14
3 16 -1.75 0 -33.75 -19.75 0 -20.14 -13.1 0 -33.75
4 16 -15.6 0 -38.75 -15.6 0 -36.25 -19.75 0 -20.14 -19.75 0 -38.75
4 16 -13.1 0 -36.25 -13.1 0 -33.75 -19.75 0 -20.14 -15.6 0 -36.25
4 16 3.75 0 -29.5 15.5 0 -13.5 12.25 0 -13.5 3.75 0 -26.85
4 16 3.75 0 -29.5 19.75 0 -29.5 19.75 0 -11 15.5 0 -13.5
3 16 15.5 0 -13.5 19.75 0 -11 15.5 0 -11
Status:
Needs 2 More Votes (N)
This part has the following automated holds from the Parts Tracker
-
Has Uncertified Subfiles
Current Votes:
None
Official parents and subparts
Part Events:
Florent Faramond [Makou]
initially submitted the part.
2023-12-22 13:25:40
Vincent Messenet [Cheenzo]
made the following comment.
2023-12-22 13:34:03
Florent Faramond [Makou]
made the following comment.
2023-12-22 13:44:45
I know :'(
I had to cheat a bit because the pixels aren't quite square...
I had to cheat a bit because the pixels aren't quite square...
Rene Rechthaler [Blechtaler]
made the following comment.
2023-12-22 15:20:02
but why are many vertexes inside a face not merged? and do we need a unpatterned version? does this version need the small unpatterned rim around the print?
Orion Pobursky [OrionP]
made the following comment.
2023-12-22 17:16:57
Yes to the last 2 questions Rene asked
Magnus Forsberg [MagFors]
posted a vote of Hold
2023-12-22 17:36:13
I can understand that the grid pattern is a good way to get the pattern right, but then is has to be reduced.
All unnecessary vertices should be removed.
Where does the part number come from? Known as 69205pb01 at Bricklink.
Do you have the part? What number is moulded on the back?
A unprinted version has to be made. Preferably using a common subpart
It looks to me that the print in the photo is misaligned, and printing close to the edge has been improved lately.
All unnecessary vertices should be removed.
Where does the part number come from? Known as 69205pb01 at Bricklink.
Do you have the part? What number is moulded on the back?
A unprinted version has to be made. Preferably using a common subpart
It looks to me that the print in the photo is misaligned, and printing close to the edge has been improved lately.
Orion Pobursky [OrionP]
posted a vote of Hold
2023-12-22 17:54:20
Rebrickable and Brickset have 73210:
https://rebrickable.com/parts/73210/tile-special-2-x-4-with-pixelated-mario-print/
But this should be 73210p01 and the unpatterned version 73210.
https://rebrickable.com/parts/73210/tile-special-2-x-4-with-pixelated-mario-print/
But this should be 73210p01 and the unpatterned version 73210.
Magnus Forsberg [MagFors]
submitted a new version of the part (all votes reset).
2024-05-22 21:40:25
Magnus Forsberg [MagFors]
submitted a new version of the part (all votes reset).
2024-05-24 16:36:05
Magnus Forsberg [MagFors]
made the following comment.
2024-05-24 16:37:03
Partnumber embossed on the backside is 69205. Think it should be renumbered.
Orion Pobursky [OrionP]
renamed the part.
2024-05-24 16:54:15
Vincent Messenet [Cheenzo]
posted a vote of Certify
2024-05-24 20:28:36
Gerald Lasser [GeraldLasser]
made the following comment.
2025-02-15 22:03:52
Here's the BI mesh, it has a grove
https://heartlake.city/dat/69121.dat
Interestingly the stud4 is much larger.
https://heartlake.city/dat/69121.dat
Interestingly the stud4 is much larger.
Takeshi Takahashi [RainbowDolphin]
posted a vote of Certify
2025-02-16 17:37:43
Magnus Forsberg [MagFors]
submitted a new version of the part (all votes reset).
2025-02-17 16:43:14
Complete rework: adding a groove, taller understud, and a unprinted border around the pattern.
Maybe the origin should be on the bottom of the stud?
Maybe the origin should be on the bottom of the stud?
