~Wedge 3 x 3 x 0.667 Cutout - without Patternable Surfaces

File Header:

0 ~Wedge  3 x  3 x  0.667 Cutout - without Patternable Surfaces
0 Name: s\3220s01.dat
0 Author: Vincent Messenet [Cheenzo]
0 !LDRAW_ORG Unofficial_Subpart
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

Show contents

1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\3220s02.dat
1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\3220s02.dat
1 16 0 4 -10 0 0 -30 -4 0 0 0 20 0 box3u4a.dat
0 BFC INVERTNEXT
1 16 0 8 -10 10 0 0 0 -5 0 0 0 16 box3u2p.dat
1 16 0 0 -20 0 0 10 0 1 0 -10 0 0 rect2p.dat
1 16 0 4 -28 10 0 0 0 4 0 0 0 -2 box2-9p.dat
1 16 0 0 0 0 0 1 0 1 0 -1 0 0 stug-3x1.dat
1 16 0 0 -20 0 0 1 0 1 0 -1 0 0 stud.dat
4 16 -30 0 10 -10 0 -10 10 0 -10 30 0 10
4 16 30 8 10 10 8 6 -10 8 6 -30 8 10
2 24 10 0 -30 10 8 -30
2 24 -10 0 -30 -10 8 -30

Status:

Needs More Votes (CN)

This part has the following automated holds from the Parts Tracker

Has uncertified subfiles

parts/s/3220s02.dat (Needs More Votes)
No path of certified files to a certified or official parent in the parts folder

Current Votes:

User	Vote
GeraldLasser	Certify

Official parents and subparts

Part Events:

Vincent Messenet [Cheenzo]

initially submitted the part.

2023-12-28 12:02:58

Philippe Hurbain [Philo]

made the following comment.

2023-12-28 14:19:38

it would be better to use stud3a instead of stud3 to avoid buried top edge that might see through sometimes.

Gerald Lasser [GeraldLasser]

posted a vote of Hold.

2025-05-20 15:40:43

That section should be simplified
3 16 -22.879 3.053 -44.506 -21.28 4.525 -46.554 -23.511 4.861 -45.514
3 16 -22.879 3.053 -44.506 -20.662 3.116 -45.739 -21.28 4.525 -46.554
3 16 -25.38 4.512 -43.963 -22.879 3.053 -44.506 -23.511 4.861 -45.514
3 16 -25.38 4.512 -43.963 -24.916 3.166 -43.254 -22.879 3.053 -44.506
3 16 -25.38 4.512 -43.963 -26 3.604 -42.639 -24.916 3.166 -43.254
3 16 -20.662 3.116 -45.739 -17.138 3.203 -47.227 -21.28 4.525 -46.554
3 16 -14 3.096 -48.042 -17.454 8 -49.885 -17.138 3.203 -47.227
3 16 -17.454 8 -49.885 -21.28 4.525 -46.554 -17.138 3.203 -47.227
3 16 -14 3.096 -48.042 -14 8 -50.701 -17.454 8 -49.885
3 16 -22.574 8 -47.662 -21.28 4.525 -46.554 -17.454 8 -49.885
3 16 -22.574 8 -47.662 -23.511 4.861 -45.514 -21.28 4.525 -46.554
3 16 -23.511 4.861 -45.514 -22.574 8 -47.662 -26 8 -45.24
3 16 -23.511 4.861 -45.514 -26 8 -45.24 -25.38 4.512 -43.963
3 16 -26 3.604 -42.639 -25.38 4.512 -43.963 -26 8 -45.24

to:
3 16 -26 3.5 -43.963 -26 .943 -40.189 -23.511 3.5 -45.514
3 16 -14 -.059 -43.873 -17.138 3.5 -47.7 -23.511 3.5 -45.514
3 16 -14 -.059 -43.873 -23.511 3.5 -45.514 -26 .943 -40.189
3 16 -17.138 3.5 -47.7 -14 -.059 -43.873 -14 3.5 -48.042
3 16 -17.138 3.5 -47.7 -14 3.5 -48.042 -14 8 -50.701
3 16 -14 8 -50.701 -17.454 8 -49.885 -17.138 3.5 -47.7
3 16 -17.454 8 -49.885 -22.574 8 -47.662 -23.511 3.5 -45.514
3 16 -23.511 3.5 -45.514 -17.138 3.5 -47.7 -17.454 8 -49.885
3 16 -23.511 3.5 -45.514 -22.574 8 -47.662 -26 8 -45.24
3 16 -23.511 3.5 -45.514 -26 8 -45.24 -26 3.5 -43.963

Instead of the stud3a use this to further reduce tha chance of artefacets of a longer stud3a bleeding through
1 16 -20 -5 -30 -1 0 0 0 -3.25 0 0 0 -1 stud3a.dat
1 16 -20 -5 -30 0 0 4 0 -1.2 0 -4 0 0 4-4cyls.dat

Vincent Messenet [Cheenzo]

made the following comment.

2025-05-21 20:18:19

This was addressed in 3220s02

Gerald Lasser [GeraldLasser]

cancelled their vote.

2025-05-21 20:55:39

Gerald Lasser [GeraldLasser]

posted a vote of Certify.

2025-05-21 21:22:48

Gerald Lasser [GeraldLasser]

posted a vote of Hold.
