Official File parts/2976c01.dat
Electric Brick 2 x 4 x 1.667 Sensor Rotation - Body Assembly
0 Electric Brick  2 x  4 x  1.667 Sensor Rotation - Body Assembly
0 Name: 2976c01.dat
0 Author: Jonathan P. Brown
0 !LDRAW_ORG Shortcut UPDATE 2017-01
0 !LICENSE Licensed under CC BY 2.0 and CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !KEYWORDS 9V, dacta, Mindstorm, RCX

0 !HISTORY 2000-09-30 [PTadmin] Official Update 2000-02
0 !HISTORY 2007-05-23 [PTadmin] Header formatted for Contributor Agreement
0 !HISTORY 2008-07-01 [PTadmin] Official Update 2008-01
0 !HISTORY 2017-01-06 [MagFors] Renamed from 2977c01 to 2976c01
0 !HISTORY 2017-12-30 [PTadmin] Official Update 2017-01
Show file code:
1 16 0 0 0 1 0 0 0 1 0 0 0 1 2976.dat
1 8 0 40 0 1 0 0 0 1 0 0 0 1 2977.dat

0 // cable
1 256 -34 38.5 0 0 -2 0 -1 0 0 0 0 1 993.dat
1 256 -36 38.5 1.3858 0 1 0 -.574025 0 -1.385819 -1.385819 0 .574025 7-8chrd.dat
1 256 -36 38.5 -1.3858 0 1 0 .574025 0 1.385819 1.385819 0 -.574025 7-8chrd.dat
1 0 -34 38 0 0 1 0 -2 0 0 0 0 4.5 rect.dat

Status

Official Official
This part has the following errors
  • Decimal precision exceeds 5 significant places
    Line 22: 1 256 -36 38.5 1.3858 0 1 0 -.574025 0 -1.385819 -1.385819 0 .574025 7-8chrd.dat
    Line 23: 1 256 -36 38.5 -1.3858 0 1 0 .574025 0 1.385819 1.385819 0 -.574025 7-8chrd.dat
