0 Minifig Tool Mallet
0 Name: 4522b.dat
0 Author: N. W. Perry [Plastikean]
0 !LDRAW_ORG Part UPDATE 2025-05
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !CATEGORY Minifig Accessory
0 !KEYWORDS BrickLink 4522, Hammer, Rebrickable 4522
0 !HISTORY 2024-02-08 [Plastikean] Corrected dimensions from 4522
0 !HISTORY 2025-05-28 [OrionP] Official Update 2025-05
Show contents
1 16 0 48 0 4 0 0 0 1 0 0 0 4 4-4edge.dat
1 16 0 0 0 4 0 0 0 1 0 0 0 4 2-4edge.dat
1 16 0 0 0 4 0 0 0 1 -1.666653 0 0 -4 2-4edge.dat
1 16 -4 -6 -10.5 0 1 0 0 0 -1.5 -1.5 0 0 3-16edge.dat
1 16 -4 -6 -10.5 0 1 0 0 0 1.5 -1.5 0 0 3-16edge.dat
1 16 4 -6 -10.5 0 -1 0 0 0 -1.5 -1.5 0 0 3-16edge.dat
1 16 4 -6 -10.5 0 -1 0 0 0 1.5 -1.5 0 0 3-16edge.dat
2 24 4 0 0 4 -4.61415 -11.07405
2 24 -4 0 0 -4 -4.61415 -11.07405
2 24 4 -12 0 4 -7.38585 -11.07405
2 24 -4 -12 0 -4 -7.38585 -11.07405
2 24 4 0 0 4 0 4
2 24 -4 0 0 -4 0 4
2 24 4 -12 0 4 -12 4
2 24 -4 -12 0 -4 -12 4
2 24 4 0 4 2.5 0 12
2 24 -4 0 4 -2.5 0 12
2 24 4 0 4 4 -1.5 12
2 24 -4 0 4 -4 -1.5 12
2 24 4 -12 4 2.5 -12 12
2 24 -4 -12 4 -2.5 -12 12
2 24 4 -12 4 4 -10.5 12
2 24 -4 -12 4 -4 -10.5 12
2 24 4 -1.5 12 2.5 0 12
2 24 -4 -1.5 12 -2.5 0 12
2 24 4 -10.5 12 2.5 -12 12
2 24 -4 -10.5 12 -2.5 -12 12
2 24 4 -1.5 12 4 -10.5 12
2 24 -4 -1.5 12 -4 -10.5 12
2 24 4 -12 0 -4 -12 0
2 24 2.5 0 12 -2.5 0 12
2 24 2.5 -12 12 -2.5 -12 12
1 16 0 0 0 4 0 0 0 48 0 0 0 4 4-4cyli.dat
1 16 0 48 0 4 0 0 0 -1 0 0 0 -4 4-4disc.dat
1 16 0 0 0 0 0 -4 0 -1.666653 0 4 0 0 1-4cyls2.dat
1 16 0 0 0 0 0 4 0 -1.666653 0 4 0 0 1-4cyls2.dat
4 16 -4 0 0 4 0 0 4 -4.61415 -11.07405 -4 -4.61415 -11.07405
4 16 -4 -12 0 -4 -7.38585 -11.07405 4 -7.38585 -11.07405 4 -12 0
1 16 -4 -6 -10.5 0 8 0 0 0 -1.5 -1.5 0 0 3-16cyli.dat
1 16 -4 -6 -10.5 0 8 0 0 0 1.5 -1.5 0 0 3-16cyli.dat
1 16 -4 -6 -10.5 0 1 0 0 0 -1.5 -1.5 0 0 3-16disc.dat
1 16 -4 -6 -10.5 0 1 0 0 0 1.5 -1.5 0 0 3-16disc.dat
1 16 4 -6 -10.5 0 -1 0 0 0 -1.5 -1.5 0 0 3-16disc.dat
1 16 4 -6 -10.5 0 -1 0 0 0 1.5 -1.5 0 0 3-16disc.dat
4 16 -4 0 0 -4 0 4 4 0 4 4 0 0
4 16 -4 -12 0 4 -12 0 4 -12 4 -4 -12 4
4 16 4 0 4 -4 0 4 -2.5 0 12 2.5 0 12
4 16 4 -12 4 2.5 -12 12 -2.5 -12 12 -4 -12 4
3 16 4 0 4 2.5 0 12 4 -1.5 12
3 16 -4 0 4 -4 -1.5 12 -2.5 0 12
3 16 4 -12 4 4 -10.5 12 2.5 -12 12
3 16 -4 -12 4 -2.5 -12 12 -4 -10.5 12
4 16 4 0 0 4 0 4 4 -6 -10.5 4 -4.61415 -11.07405
4 16 4 -12 0 4 -7.38585 -11.07405 4 -6 -10.5 4 -12 4
3 16 4 0 4 4 -12 4 4 -6 -10.5
4 16 4 0 4 4 -1.5 12 4 -10.5 12 4 -12 4
4 16 -4 -4.61415 -11.07405 -4 -6 -10.5 -4 0 4 -4 0 0
4 16 -4 -12 4 -4 -6 -10.5 -4 -7.38585 -11.07405 -4 -12 0
3 16 -4 -6 -10.5 -4 -12 4 -4 0 4
4 16 -4 -12 4 -4 -10.5 12 -4 -1.5 12 -4 0 4
4 16 4 -1.5 12 2.5 0 12 2.5 -12 12 4 -10.5 12
4 16 -4 -1.5 12 -4 -10.5 12 -2.5 -12 12 -2.5 0 12
4 16 2.5 0 12 -2.5 0 12 -2.5 -12 12 2.5 -12 12
5 24 4 -4.61415 -11.07405 -4 -4.61415 -11.07405 -4 0 0 -4 -5.866 -11.298
5 24 -4 -7.38585 -11.07405 4 -7.38585 -11.07405 -4 -12 0 -4 -6.634 -11.298
