File Detail parts/s/u9226s01.dat

Unofficial File parts/s/u9226s01.dat

~Train Track 12V Tapered Point Vertical Axle Common

File Header:

0 ~Train Track 12V Tapered Point Vertical Axle Common
0 Name: s\u9226s01.dat
0 Author: Rene Rechthaler [Blechtaler]
0 !LDRAW_ORG Unofficial_Subpart
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

Show contents

1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\u9226s02.dat
1 16 0 0 0 1 0 0 0 1 0 0 0 -1 s\u9226s02.dat
1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\u9226s02.dat
1 16 0 0 0 -1 0 0 0 1 0 0 0 -1 s\u9226s02.dat
0 // Top
1 16 0 -18 0 2.82843 0 -2.82843 0 1 0 2.82843 0 2.82843 4-4ndis.dat
0 BFC INVERTNEXT
1 16 0 16 0 2.82843 0 -2.82843 0 -34 0 2.82843 0 2.82843 4-4cylc.dat
1 16 0 -9 6.00535 2.48755 0 0 0 0 9 0 -1 0 rect.dat
1 16 0 -9 -6.00535 2.48755 0 0 0 0 9 0 1 0 rect.dat
3 16 2.48755 -18 6.00535 -2.48755 -18 6.00535 0 -18 5.65686
3 16 2.48755 -18 -6.00535 0 -18 -5.65686 -2.48755 -18 -6.00535
3 16 2.48755 0 6.00535 0 0 7 -2.48755 0 6.00535
3 16 0 0 -7 2.48755 0 -6.00535 -2.48755 0 -6.00535
0 // Side knobs
1 16 0 13.5 6.502874 0 0 2.5 2.5 0 0 0 4.897126 0 box3u2p.dat
1 16 0 13.5 -6.502874 0 0 2.5 2.5 0 0 0 -4.897126 0 box3u2p.dat
3 16 0 11 7 2.5 11 11.4 -2.5 11 11.4
3 16 2.5 11 -11.4 0 11 -7 -2.5 11 -11.4
3 16 2.5 16 11.4 0 16 12 -2.5 16 11.4
3 16 0 16 -12 2.5 16 -11.4 -2.5 16 -11.4
5 24 0 0 7 0 11 7 -2.5 11 6.502874 2.5 11 6.502874
5 24 0 0 -7 0 11 -7 2.5 11 -6.502874 -2.5 11 -6.502874

0 // Teeth
1 16 0 25 0 6 0 0 0 -1 0 0 0 6 4-4ring1.dat
1 16 0 25 0 6 0 0 0 -1 0 0 0 6 4-4ering.dat
1 16 0 25 0 -3 0 0 0 5 0 0 0 3 1-16cyli.dat
1 16 0 25 0 -3 0 0 0 5 0 0 0 -3 1-16cyli.dat
1 16 0 25 0 -3 0 0 0 1 0 0 0 3 1-16edge.dat
1 16 0 25 0 -3 0 0 0 1 0 0 0 -3 1-16edge.dat
1 16 0 25 0 -3 0 0 0 -1 0 0 0 3 1-16tang.dat
1 16 0 25 0 -3 0 0 0 -1 0 0 0 -3 1-16tang.dat
4 16 -4.2426 25 4.2426 -2.7717 25 1.1481 -3 25 .5967 -5.5434 25 2.2962
4 16 -6 25 0 -5.5434 25 2.2962 -3 25 .5967 -3 25 0
4 16 -6 25 0 -3 25 0 -3 25 -.5967 -5.5434 25 -2.2962
4 16 -5.5434 25 -2.2962 -3 25 -.5967 -2.7717 25 -1.1481 -4.2426 25 -4.2426
2 24 0 25 6 0 30 6
2 24 0 25 -6 0 30 -6
1 16 0 30 0 3 0 0 0 -1 0 0 0 3 1-16tang.dat
1 16 0 30 0 3 0 0 0 -1 0 0 0 -3 1-16tang.dat
1 16 4.385825 27.5 -.574025 -1.614175 -1 0 0 0 2.5 -.574025 0 0 rect2p.dat
1 16 4.385825 27.5 .574025 1.614175 -1 0 0 0 2.5 -.574025 0 0 rect2p.dat
3 16 2.77165 30 -1.14805 3 30 -.5967 6 30 0
3 16 3 30 -.5967 3 30 0 6 30 0
3 16 6 30 0 3 30 0 3 30 .5967
3 16 3 30 .5967 2.77165 30 1.14805 6 30 0
4 16 4.2426 25 -4.2426 2.7717 25 -1.1481 6 25 0 5.5434 25 -2.2962
4 16 6 25 0 2.7717 25 1.1481 4.2426 25 4.2426 5.5434 25 2.2962
2 24 6 30 0 6 25 0
1 16 0 30 0 3 0 0 0 6 0 0 0 3 4-4cyli.dat
1 16 0 30 0 3 0 0 0 1 0 0 0 3 7-16edge.dat
1 16 0 30 0 3 0 0 0 1 0 0 0 -3 7-16edge.dat
1 16 0 36 0 .5 0 0 0 -1 0 0 0 .5 4-4ring5.dat
1 16 0 36 0 3 0 0 0 1 0 0 0 3 4-4edge.dat
0 BFC INVERTNEXT
1 16 0 25 0 2.5 0 0 0 11 0 0 0 2.5 4-4cylc.dat

Status:

Needs More Votes (CN)

This part has the following automated holds from the Parts Tracker

Has uncertified subfiles

parts/s/u9226s02.dat (Needs More Votes)
No path of certified files to a certified or official parent in the parts folder

Current Votes:

User	Vote
RainbowDolphin	Certify

Official parents and subparts

Part Events:

Rene Rechthaler [Blechtaler]

initially submitted the part.

2024-03-02 15:12:17

Rene Rechthaler [Blechtaler]

submitted a new version of the part.

2024-05-12 16:50:06

deeper bottom hole

Takeshi Takahashi [RainbowDolphin]

posted a vote of Certify.

2024-05-31 15:25:24
