Gap on right shoulder
3 16 -14 0 8 -12 0 10 -14.345 2 10
3 0 -13 .86 10 -12.5 .43 10 -11.39 1.36 10
4 321 -13 .86 10 -12.61 1.36 10 -13.67 1.73 10 -13.27 1.09 10

some vertices are not on the left shoulder, need a few more decimals to be on the line
3 0 13.15 .98 10 12.69 1.33 10 12.57 .49 10
4 0 12.57 .49 10 12.69 1.33 10 12.13 1.77 10 11.54 1.24 10
4 16 11.54 1.24 10 6.91 .31 10 12 0 10 12.57 .49 10
3 16 14.345 2 10 13.67 1.61 10 13.15 .98 10
3 321 13.67 1.61 10 12.69 1.33 10 13.15 .98 10

should be like:
3 0 13.1496 .98047 10 12.69 1.33 10 12.5719 .48777 10
4 0 12.5719 .48777 10 12.69 1.33 10 12.13 1.77 10 11.54 1.24 10
4 16 11.54 1.24 10 6.91 .31 10 12 0 10 12.5719 .48777 10
3 16 14.345 2 10 13.67 1.61 10 13.1496 .98047 10
3 321 13.67 1.61 10 12.69 1.33 10 13.1496 .98047 10

Or you don't extend the pattern till the edge

split this
4 0 8.38 25.69 10 7.79 24.95 10 13.08 24.89 10 11.47 25.63 10

to those:
3 0 10.51 25.65 10 8.38 25.69 10 7.79 24.95 10
4 0 7.79 24.95 10 13.08 24.89 10 11.47 25.63 10 10.51 25.65 10

There are a few trianlges missing at teh bottom back where the pinstripes meet the edge of the part.

I want to avoid thin triangles, but sometimes they are needed (or missing) ;)

True, it is a pain to add them and sometimes difficult to spot if they are at the correct place where you want them to be

I could not see the thin ones around the shoulded in LDPE properly...needed LDView

There is one vertex in the middle of the back which has excessive decimals:
0 !LPE VERTEX 10.5099736328125 25.648640625 10

At first I thought this is at a corner or edge line but it could easily be shortened.

Release 2024-07
