File Detail parts/862bp01.dat

Download Download zip file View patterns/composites/shortcuts

Unofficial File parts/862bp01.dat

Part Attributes: Base Part: 862b.dat

Train Track 12V Straight Insert Type 3 with Isolation and Black Triangle Pattern

File Header:

0 Train Track 12V Straight Insert Type 3 with Isolation and Black Triangle Pattern
0 Name: 862bp01.dat
0 Author: Rene Rechthaler [Blechtaler]
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 !HELP There exist 2 more variants of this part,
0 !HELP one with the isolation at the center and
0 !HELP its pattern, with a black top triangle at the part center.
0 !HELP Note that the central underside rim fully extends to the part bottom
0 !HELP (different than 3240a, 3240b)
0 !HELP place 2775c01
0 !HELP 1 16 -90 9.5 20 1 0 0 0 1 0 0 0 1 2775c01.dat
0 !HELP place 2x 765c01.dat
0 !HELP 1 16 -107.5 9.5 20 0 1 0 1 0 0 0 0 1 765c01.dat
0 !HELP 1 16 -72.5 9.5 20 0 -1 0 1 0 0 0 0 1 765c01.dat

0 BFC CERTIFY CCW

0 !KEYWORDS Set 7860

0 !CMDLINE -c7

0 !HISTORY 2024-07-12 [Blechtaler] made from 862a.dat by [Steffen]
