0 Electric Train Light Prism  4 x  4
0 Name: 46309.dat
0 Author: Gerald Lasser [GeraldLasser]
0 !LDRAW_ORG Part UPDATE 2024-10
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2024-12-01 [OrionP] Official Update 2024-10

Show contents

1 16 0 4 -18 6 0 0 0 1 0 0 0 -6 2-4ndis.dat
1 16 0 16 -18 6 0 0 0 -1 0 0 0 -6 2-4ndis.dat
0 BFC INVERTNEXT
1 16 0 4 -18 6 0 0 0 12 0 0 0 -6 2-4cylo.dat
3 16 0 10 -32 -4.2426 10 -33.7574 4.2426 10 -33.7574
3 16 -4.2426 13.5 -33.7574 0 13.5 -32 4.2426 13.5 -33.7574
4 16 -4.2426 13.5 -33.7574 4.2426 13.5 -33.7574 9.4911 13.5 -39 -9.4911 13.5 -39
1 16 0 11.75 -39 0 0 9.4911 1.75 0 0 0 1 0 rect.dat
4 16 -9.4911 10 -39 9.4911 10 -39 4.2426 10 -33.7574 -4.2426 10 -33.7574

1 16 0 10 -18 1 0 0 0 1 0 0 0 1 s\46309s01.dat
1 16 0 10 -18 -1 0 0 0 1 0 0 0 1 s\46309s01.dat
