0 Technic Competition Cannon with Flat Bottom with Long Trigger (Loaded with Arrow)
0 Name: 57796ac02.dat
0 Author: Santeri Piippo [arezey]
0 !LDRAW_ORG Shortcut UPDATE 2024-08
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 !HELP The position of the inserted arrow is:
0 !HELP 1 16 0 -26 0 1 0 0 0 1 0 0 0 1 57028p01.dat
0 BFC CERTIFY CCW
0 !HISTORY 2024-07-05 [Holly-Wood] Changed spring position, fixed comment
0 !HISTORY 2024-09-15 [GeraldLasser] Changed spring position
0 !HISTORY 2024-09-30 [OrionP] Official Update 2024-08
1 16 0 0 0 1 0 0 0 1 0 0 0 1 57029ac01.dat
1 494 0 -26 25.5 0 0 1 -1 0 0 0 -1 0 71830-f2.dat
1 16 0 -19 37 1 0 0 0 1 0 0 0 1 32075.dat
1 16 0 -26 0 1 0 0 0 1 0 0 0 1 57028p01.dat
are these always paired with that arrow? (there are other colors too, both rubber and shaft)
is the trigger always the same color?
The default position should be fully vertical, since the spring pushes everything forward when loaded.
It even had the same position in the unloaded assy. The sping push on the trigger and "force" the trigger to an upright position.
It will only be in the tilted position when I pull it back to release the arrow, and then returns to the uppright position.
But I'm not sure.
There could be a gradual transition from the older 76100 (round/long) to the newer 57796 (flat/short), where first the barrel is changed and later the trigger.
there are also some 2006 sets which have flat and round arrows as alternates.
->gradual change
help:
0 !HELP The position of the inserted arrow is:
0 !HELP 1 16 0 -26 -1 1 0 0 0 1 0 0 0 1 57028p01.dat
to
0 !HELP The position of the inserted arrow is:
0 !HELP 1 16 0 -26 0 1 0 0 0 1 0 0 0 1 57028p01.dat
description:
Technic Competition Cannon with Flat Bottom with Trigger "Loaded" (with an arrow)
to
Technic Competition Cannon with Flat Bottom with Trigger (Loaded with Arrow)
description:
Technic Competition Cannon with Flat Bottom with Trigger (Loaded with Arrow)
to
Technic Competition Cannon with Flat Bottom with Long Trigger (Loaded with Arrow)
need to wait for new springs to cater for the new distances
