Unofficial File parts/s/u9602s02.dat
File Header:
0 ~Electric Train 12V Transformer Type 1 Red Dot
0 Name: s\u9602s02.dat
0 Author: Rene Rechthaler [Blechtaler]
0 !LDRAW_ORG Unofficial_Subpart
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
Show contents
1 16 0 -1 0 12.5 0 0 0 1 0 0 0 12.5 4-4cylc.dat
1 16 0 -1 0 0 0 2 0 2 0 -2 0 0 logo5.dat
Status:
Awaiting Admin Review (CCN)
This part has the following automated holds from the Parts Tracker
- No path of certified files to a certified or official parent in the parts folder
Current Votes:
| User | Vote |
|---|---|
| Holly-Wood | Certify |
| RainbowDolphin | Certify |
Official parents and subparts
Part Events:
the small red lamp cover
2025-08-26 06:35:40
The logo is just edge lines on a flat surface, this is not seen if this is rendered. it can only be seen in LDView.
I would go for one of the raised ones, logo3 or logo4, which have a 3D geometry
I would go for one of the raised ones, logo3 or logo4, which have a 3D geometry
3D Logo
2025-08-26 09:40:23
does this need the rear clip (and the corresponding hole in u9602)?
2025-08-26 09:55:35
you made the dot colour 4 , which is opaque, so IMHO ok.
If you would make it transparent (as it is sopposed to hide a lamp(?)), I would go for the hole, but then you need to add some visibility blocker as well
If you would make it transparent (as it is sopposed to hide a lamp(?)), I would go for the hole, but then you need to add some visibility blocker as well
2025-08-26 09:56:55
I yould give to logo in y direction also a scaling of 2
equally sized logo5
2025-08-26 13:58:13
2025-08-27 13:44:32
Creative Commons Attribution License information
This part is copyright © Rene Rechthaler
Licensed under CC BY 4.0
