File Detail parts/5650.dat

Official File parts/5650.dat

Part Attributes:

External Sites:

View on Rebrickable View on BrickLink View on BrickOwl

File Header:

0 Wheel Rim 20 x 30 with  5 Holes
0 Name: 5650.dat
0 Author: Philippe Hurbain [Philo]
0 !LDRAW_ORG Part UPDATE 2024-10
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !KEYWORDS 30.4 x 20

0 !HISTORY 2024-10-04 {LEGO Instructions App} Original part shape
0 !HISTORY 2024-10-06 [Philo] File preparation for LDraw Parts Tracker
0 !HISTORY 2024-12-01 [OrionP] Official Update 2024-10

Show contents

1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\5650s02.dat
1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\5650s02.dat

1 16 0 0 20 9 0 0 0 0 9 0 -5.7 0 4-4cylo.dat
1 16 0 0 0 9 0 0 0 0 9 0 9.8 0 4-4cylo.dat
1 16 0 0 0 1 0 0 0 0 1 0 20 0 axl3hole.dat
1 16 0 0 0 3 0 0 0 0 3 0 1 0 4-4ring2.dat
1 16 0 0 20 3 0 0 0 0 3 0 -1 0 4-4ring2.dat
1 16 0 0 0 6 0 0 0 0 6 0 1 0 4-4ering.dat
1 16 0 0 20 6 0 0 0 0 6 0 -1 0 4-4ering.dat
1 16 0 0 -25 38 0 0 0 0 38 0 4 0 48\4-4cylo.dat
1 16 0 0 -21 3.8 0 0 0 0 3.8 0 -1 0 48\4-4ring9.dat
1 16 0 0 -21 34.2 0 0 0 0 34.2 0 6 0 48\4-4cylo.dat
1 16 0 0 -25 3.8 0 0 0 0 3.8 0 1 0 48\4-4ring9.dat
1 16 0 0 -15 3.8 0 0 0 0 3.8 0 1 0 48\4-4ring9.dat
1 16 0 0 -12 4.75 0 0 0 0 4.75 0 -1 0 48\4-4ring7.dat
1 16 0 0 -15 38 0 0 0 0 38 0 3 0 48\4-4cylo.dat
0 BFC INVERTNEXT
1 16 0 0 -25 3.42 0 0 0 0 3.42 0 3.2 0 48\4-4con9.dat
1 16 0 0 -25 34.2 0 0 0 0 34.2 0 1 0 48\4-4edge.dat
1 16 0 0 -21.8 30.78 0 0 0 0 30.78 0 1 0 48\4-4edge.dat
1 16 0 0 25 38 0 0 0 0 38 0 -4 0 48\4-4cylo.dat
1 16 0 0 21 3.8 0 0 0 0 3.8 0 1 0 48\4-4ring9.dat
1 16 0 0 21 34.2 0 0 0 0 34.2 0 -6 0 48\4-4cylo.dat
1 16 0 0 25 3.8 0 0 0 0 3.8 0 -1 0 48\4-4ring9.dat
1 16 0 0 15 3.8 0 0 0 0 3.8 0 -1 0 48\4-4ring9.dat
1 16 0 0 15 38 0 0 0 0 38 0 -3 0 48\4-4cylo.dat
0 BFC INVERTNEXT
1 16 0 0 25 3.42 0 0 0 0 3.42 0 -3.2 0 48\4-4con9.dat
1 16 0 0 25 34.2 0 0 0 0 34.2 0 -1 0 48\4-4edge.dat
0 BFC INVERTNEXT
1 16 0 0 21.8 30.78 0 0 0 0 30.78 0 -7.5 0 48\4-4cylo.dat
0 BFC INVERTNEXT
1 16 0 0 -21.8 30.78 0 0 0 0 30.78 0 17 0 48\4-4cyli.dat
1 16 0 0 -7.2 30.78 0 0 0 0 30.78 0 1 0 48\4-4edge.dat
5 24 0 34.117 -12 0 34.117 -4.568 3.566 33.93 -4.568 -3.566 33.93 -4.568
5 24 0 34.117 -4.568 0 32.604 -2.349 3.534 32.452 -2.406 -3.534 32.452 -2.406
5 24 0 12.1135 8.172 0 15.918 5.727 -2.289 14.0525 6.7915 2.289 14.0525 6.7915
5 24 0 -12.5 14.3 0 -12.5 8.137 -1.941 -12.7558 7.87 1.941 -12.7558 7.87
5 24 0 21.532 2.119 0 24.742 0.055 3.427 22.232 1.479 -3.427 22.232 1.479
5 24 0 32.604 -2.349 0 29.101 1.473 -3.436 29.034 1.352 3.436 29.034 1.352
5 24 0 9.248 9.8 0 12.1135 8.172 2.248 11.144 8.63 -2.248 11.144 8.63
5 24 0 27.114 -1.778 0 29.272 -4.346 4.603 28.896 -4.386 -4.603 28.896 -4.386
5 24 0 -29.2265 -4.3395 0 -27.5 -2.263 -1.941 -27.2443 -2.084 1.941 -27.2443 -2.084
2 24 0 19.871 7.675 0 19.871 12
5 24 0 29.101 1.473 0 26.0075 3.6965 2.776 25.922 3.6515 -2.776 25.922 3.6515
5 24 0 -12.5 8.137 0 -9.2384 9.8 -2.5487 -8.9113 9.8 2.5487 -8.9113 9.8
5 24 0 -36.9723 12 0 -36.9723 -12 -1.2575 -36.5071 -12 1.2575 -36.5071 -12
5 24 0 18.757 3.902 0 21.532 2.119 3.427 22.232 1.479 -3.427 22.232 1.479
5 24 0 26.0075 3.6965 0 19.871 7.675 0.839 20.399 7.291 -0.839 20.399 7.291
5 24 0 -27.5 -2.263 0 -27.5 14.3 -1.941 -27.2443 14.3 1.941 -27.2443 14.3
5 24 0 15.918 5.727 0 18.757 3.902 -2.679 19.6845 3.177 2.679 19.6845 3.177
5 24 0 24.742 0.055 0 27.114 -1.778 4.1855 25.5555 -0.8715 -4.1855 25.5555 -0.8715
5 24 0 -29.2267 -4.3395 0 -30.78 -7.2 4.01679 -30.515292 -7.2 -4.0168 -30.5153 -7.2
5 24 0 30.78 -7.2 0 29.272 -4.346 4.01679 30.515292 -7.2 -4.0168 30.5153 -7.2

Status:

Official

Unofficial parents

Part Events:

Archived Part Events:

Philippe Hurbain [Philo]

initially submitted the part.

2024-10-06 10:03:42

Gerald Lasser [GeraldLasser]

posted a vote of Hold.

2024-10-07 10:18:32

I think the intersection between the 48 cyli and the subfiles should be done with edgelines
not with the 1 16 0 0 -7.287 30.78 0 0 0 0 30.78 0 1 0 48\4-4edge.dat

Philippe Hurbain [Philo]

made the following comment.

2024-10-08 11:46:23

I initially tried that, but I find that the 4-4edge look better. Lines seem jagged while the little misfit of edge line is barely visible. I'm OK to change though ;)

Gerald Lasser [GeraldLasser]

made the following comment.

2024-10-08 14:22:40

what about moving the edge closer to the intersection?

Rene Rechthaler [Blechtaler]

made the following comment.

2024-10-08 15:32:24

i think the whole family of "Wheel Rim 20 x 30" and its corresponding tyres should get reworked to use the same beads (made from hi-res prims like here)

Philippe Hurbain [Philo]

made the following comment.

2024-10-08 18:50:53

I placed the edge line on the very top of intersection lines so that no part of it is hidden (I calculated the intersection line and took the max point of all segments)
"i think the whole family should get reworked" Why loose time on parts that worked well enough for years, when there are gazillion of useful missing ones ???

Gerald Lasser [GeraldLasser]

cancelled their vote.

2024-10-08 19:48:28

Philippe Hurbain [Philo]

submitted a new version of the part.

2024-10-09 12:28:56

Changed intersection to avoid jagged lines. Cylinder kept intentionally longer to minimize gap visibility at very high prim subst level.

Gerald Lasser [GeraldLasser]

posted a vote of Certify.

2024-10-17 22:42:49

Takeshi Takahashi [RainbowDolphin]

posted a vote of Certify.
