0 ~Hinge 6 x 3 Radar without Patternable Surface
0 Name: s\2440s01.dat
0 Author: Takeshi Takahashi [RainbowDolphin]
0 !LDRAW_ORG Unofficial_Subpart
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2004-10-19 [fwcain] Subfiled "main" (i.e., non-patterned) part
0 !HISTORY 2004-12-12 [cwdee] Correct stud4 usage and BFCd
0 !HISTORY 2005-12-28 [PTadmin] Official Update 2005-01
0 !HISTORY 2007-08-28 [PTadmin] Header formatted for Contributor Agreement
0 !HISTORY 2008-07-01 [PTadmin] Official Update 2008-01
0 !HISTORY 2008-07-07 [nielsk] Fixed incorrect lines, update using more primitives (2006-01-09)
0 !HISTORY 2011-07-25 [PTadmin] Official Update 2011-01
0 !HISTORY 2024-10-18 [RainbowDolphin] Made BFC CCW and total rewrite for CC-BY 4.0, original by John Van Zwieten [jvan]
