~Pin Hollow for Electric Plug (Type 1) Twin or Single

0 ~Pin Hollow for Electric Plug (Type 1) Twin or Single
0 Name: u9238.dat
0 Author: Steffen [Steffen]
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !CATEGORY Electric

0 !HISTORY 2012-11-05 [mikeheide] Added some lines for demonstration
0 !HISTORY 2022-01-22 [mikeheide] Made it more like a foil. Still the gap missing and the tip slanting.
0 !HISTORY 2022-07-18 [PTadmin] Official Update 2022-04
0 !HISTORY 2024-03-23 [OrionP] Updated ring primitives
0 !HISTORY 2024-03-24 [OrionP] Official Update 2024-02
0 !HISTORY 2024-10-23 [Blechtaler] Added Screwhole
