0 Slope Brick Curved 3 x 4 x 1.333 Rounded
0 Name: 5787.dat
0 Author: Philippe Hurbain [Philo]
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2024-10-31 {LEGO Instructions App} Original part shape
0 !HISTORY 2024-11-06 [Philo] File preparation for LDraw Parts Tracker
Show contents
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\5787s01.dat
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\5787s03.dat
1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\5787s03.dat
