File Detail parts/6429457e.dat

Download Download zip file View sticker sheet parts

Official File parts/6429457e.dat

Part Attributes:

External Sites:

View on Rebrickable View on BrickLink View on BrickOwl

File Header:

0 Sticker  1.8 x  3.0 with Blacktron I Logo
0 Name: 6429457e.dat
0 Author: Gabriel Läufer [Dr.Bricktacular]
0 !LDRAW_ORG Part UPDATE 2025-02
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !KEYWORDS Blacktron Cruiser, Bricklink 40580stk01, Brickowl 402277
0 !KEYWORDS Rebrickable 10102362, Set 40580

0 !HISTORY 2025-02-27 [OrionP] Official Update 2025-02

Show contents

0 // Sticker-Bottom
1 16 16.5 0 -29.0 1 0 0 0 -1 0 0 0 -1 1-4chrd.dat
1 16 16.5 0 29.0 1 0 0 0 -1 0 0 0 1 1-4chrd.dat
1 16 -16.5 0 -29.0 -1 0 0 0 -1 0 0 0 -1 1-4chrd.dat
1 16 -16.5 0 29.0 -1 0 0 0 -1 0 0 0 1 1-4chrd.dat
4 16 17.5 0 29.0 17.5 0 -29.0 16.5 0 -30.0 16.5 0 30.0
4 16 -17.5 0 29.0 -16.5 0 30.0 -16.5 0 -30.0 -17.5 0 -29.0
4 16 16.5 0 30.0 16.5 0 -30.0 -16.5 0 -30.0 -16.5 0 30.0

0 // Sticker-Side
1 16 16.5 -0.25 -29.0 1 0 0 0 0.25 0 0 0 -1 1-4cyli.dat
1 16 16.5 -0.25 29.0 1 0 0 0 0.25 0 0 0 1 1-4cyli.dat
1 16 -16.5 -0.25 -29.0 -1 0 0 0 0.25 0 0 0 -1 1-4cyli.dat
1 16 -16.5 -0.25 29.0 -1 0 0 0 0.25 0 0 0 1 1-4cyli.dat
4 16 17.5 0 29.0 17.5 -0.25 29.0 17.5 -0.25 -29.0 17.5 0 -29.0
4 16 -17.5 0 29.0 -17.5 0 -29.0 -17.5 -0.25 -29.0 -17.5 -0.25 29.0
4 16 -16.5 0 30.0 -16.5 -0.25 30.0 16.5 -0.25 30.0 16.5 0 30.0
4 16 -16.5 0 -30.0 16.5 0 -30.0 16.5 -0.25 -30.0 -16.5 -0.25 -30.0

0 // Sticker-Front
1 0 -16.5 -.25 -29 -1 0 0 0 1 0 0 0 -1 1-4chrd.dat
1 0 -16.5 -.25 29 -1 0 0 0 1 0 0 0 1 1-4chrd.dat
1 0 16.5 -.25 29 1 0 0 0 1 0 0 0 1 1-4chrd.dat
1 0 16.5 -.25 -29 1 0 0 0 1 0 0 0 -1 1-4chrd.dat
3 0 0 -.25 -12.2 7.3 -.25 3.6 -7.3 -.25 3.6
3 14 0 -.25 -12.2 15.3 -.25 -12.2 7.3 -.25 3.6
3 14 -15.3 -.25 -12.2 0 -.25 -12.2 -7.3 -.25 3.6
3 14 -7.3 -.25 3.6 7.3 -.25 3.6 0 -.25 18
4 0 -16.5 -.25 -30 16.5 -.25 -30 0 -.25 -12.2 -17.5 -.25 -29
3 0 -17.5 -.25 -29 0 -.25 -12.2 -15.3 -.25 -12.2
4 0 0 -.25 18 -16.5 -.25 30 -17.5 -.25 29 -7.3 -.25 3.6
3 0 -15.3 -.25 -12.2 -7.3 -.25 3.6 -17.5 -.25 29
4 0 16.5 -.25 30 -16.5 -.25 30 0 -.25 18 17.5 -.25 29
3 0 17.5 -.25 29 0 -.25 18 7.3 -.25 3.6
3 0 7.3 -.25 3.6 15.3 -.25 -12.2 17.5 -.25 29
3 0 -17.5 -.25 -29 -15.3 -.25 -12.2 -17.5 -.25 29
4 0 17.5 -.25 -29 15.3 -.25 -12.2 0 -.25 -12.2 16.5 -.25 -30
3 0 17.5 -.25 -29 17.5 -.25 29 15.3 -.25 -12.2

Status:

Official

Unofficial parents

Part Events:

Archived Part Events:

Gabriel Läufer [Dr.Bricktacular]

initially submitted the part.

2025-01-26 19:54:09

Chris Böhnke [KnightOfTarenta]

posted a vote of Hold.

2025-01-27 00:23:03

*the 2 outer most vertices of the logo triangles are not completely symmetrical
*I think this should be a bit more centered, but I am not sure

Chris Böhnke [KnightOfTarenta]

made the following comment.

2025-01-27 00:24:46

What I meant is the 15.3/-15.4 in these two lines:
3 14 0 -0.25 12.2 -15.4 -0.25 12.2 -7.3 -0.25 -3.6
3 14 15.3 -0.25 12.2 0 -0.25 12.2 7.3 -0.25 -3.6

Chris Böhnke [KnightOfTarenta]

edited the part header.

2025-01-27 00:25:40

Header Edits

keywords:
Blacktron Cruiser, Blacktron I, Bricklink 40580stk01, Brickowl 402277, Rebrickable 10102362, Set 40580
to
Blacktron Cruiser, Bricklink 40580stk01, Brickowl 402277, Rebrickable 10102362, Set 40580
