Official File parts/u9309.dat
Part Attributes:
File Header:
0 ~Train Track 9V Switch Right - Straight Metal Rail
0 Name: u9309.dat
0 Author: Max Martin Richter [MMR1988]
0 !LDRAW_ORG Part UPDATE 2025-08
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2025-08-31 [OrionP] Official Update 2025-08
Show contents
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\u9611s03.dat
1 16 -28.25 0 0 1 0 0 0 1 0 0 0 1 s\u9611s02.dat
1 16 -118.25 0 0 1 0 0 0 1 0 0 0 1 s\u9611s02.dat
1 16 -198.25 0 0 1 0 0 0 1 0 0 0 1 s\u9611s02.dat
3 16 -217.75 -11.25 3.125 -217.75 -16 3.125 -203.25 -11.25 3.125
3 16 -203.25 -11.25 3.125 -217.75 -16 3.125 -193.25 -11.25 3.125
3 16 -193.25 -11.25 3.125 -217.75 -16 3.125 -123.25 -11.25 3.125
4 16 -113.25 -11.25 3.125 -123.25 -11.25 3.125 -217.75 -16 3.125 -10.75 -16 3.125
3 16 -10.75 -16 3.125 -33.25 -11.25 3.125 -113.25 -11.25 3.125
3 16 -10.75 -16 3.125 -23.25 -11.25 3.125 -33.25 -11.25 3.125
3 16 -10.75 -11.25 3.125 -23.25 -11.25 3.125 -10.75 -16 3.125
4 16 -203.25 -11.5 2.625 -217.75 -15.5 2.625 -217.75 -11.25 2.625 -203.25 -11.25 2.625
3 16 -217.75 -15.5 2.625 -203.25 -11.5 2.625 -193.25 -11.5 2.625
3 16 -217.75 -15.5 2.625 -193.25 -11.5 2.625 -123.25 -11.5 2.625
4 16 -113.25 -11.5 2.625 -10.75 -15.5 2.625 -217.75 -15.5 2.625 -123.25 -11.5 2.625
3 16 -33.25 -11.5 2.625 -10.75 -15.5 2.625 -113.25 -11.5 2.625
3 16 -10.75 -15.5 2.625 -33.25 -11.5 2.625 -23.25 -11.5 2.625
4 16 -10.75 -15.5 2.625 -23.25 -11.5 2.625 -23.25 -11.25 2.625 -10.75 -11.25 2.625
4 16 -113.25 -11.25 2.625 -33.25 -11.25 2.625 -33.25 -11.5 2.625 -113.25 -11.5 2.625
4 16 -193.25 -11.25 2.625 -123.25 -11.25 2.625 -123.25 -11.5 2.625 -193.25 -11.5 2.625
4 16 -217.75 -11.25 -2.625 -217.75 -15.5 -2.625 -203.25 -11.5 -2.625 -203.25 -11.25 -2.625
3 16 -203.25 -11.5 -2.625 -217.75 -15.5 -2.625 -193.25 -11.5 -2.625
3 16 -123.25 -11.5 -2.625 -193.25 -11.5 -2.625 -217.75 -15.5 -2.625
4 16 -113.25 -11.5 -2.625 -123.25 -11.5 -2.625 -217.75 -15.5 -2.625 8.25 -15.5 -2.625
3 16 -33.25 -11.5 -2.625 -113.25 -11.5 -2.625 8.25 -15.5 -2.625
3 16 -33.25 -11.5 -2.625 8.25 -15.5 -2.625 -23.25 -11.5 -2.625
4 16 -23.25 -11.5 -2.625 8.25 -15.5 -2.625 8.25 -11.25 -2.625 -23.25 -11.25 -2.625
4 16 -113.25 -11.25 -2.625 -113.25 -11.5 -2.625 -33.25 -11.5 -2.625 -33.25 -11.25 -2.625
4 16 -193.25 -11.25 -2.625 -193.25 -11.5 -2.625 -123.25 -11.5 -2.625 -123.25 -11.25 -2.625
3 16 -217.75 -16 -3.125 -217.75 -11.25 -3.125 -203.25 -11.25 -3.125
3 16 -217.75 -16 -3.125 -203.25 -11.25 -3.125 -193.25 -11.25 -3.125
3 16 -217.75 -16 -3.125 -193.25 -11.25 -3.125 -123.25 -11.25 -3.125
4 16 -217.75 -16 -3.125 -123.25 -11.25 -3.125 -113.25 -11.25 -3.125 8.25 -16 -3.125
3 16 -113.25 -11.25 -3.125 -33.25 -11.25 -3.125 8.25 -16 -3.125
3 16 -33.25 -11.25 -3.125 -23.25 -11.25 -3.125 8.25 -16 -3.125
3 16 8.25 -16 -3.125 -23.25 -11.25 -3.125 8.25 -11.25 -3.125
1 16 -210.5 -11.25 -2.875 7.25 0 0 0 -1 0 0 0 -.25 rect.dat
1 16 -158.25 -11.25 -2.875 35 0 0 0 -1 0 0 0 -.25 rect.dat
1 16 -73.25 -11.25 -2.875 40 0 0 0 -1 0 0 0 -.25 rect.dat
1 16 -7.5 -11.25 -2.875 -15.75 0 0 0 -1 0 0 0 .25 rect.dat
1 16 -210.5 -11.25 2.875 7.25 0 0 0 -1 0 0 0 .25 rect.dat
1 16 -158.25 -11.25 2.875 35 0 0 0 -1 0 0 0 .25 rect.dat
1 16 -73.25 -11.25 2.875 40 0 0 0 -1 0 0 0 .25 rect.dat
1 16 -17 -11.25 2.875 -6.25 0 0 0 -1 0 0 0 .25 rect.dat
4 16 -217.75 -11.25 2.625 -217.75 -15.5 2.625 -217.75 -16 3.125 -217.75 -11.25 3.125
4 16 -217.75 -15.5 -2.625 -217.75 -16 -3.125 -217.75 -16 3.125 -217.75 -15.5 2.625
4 16 -217.75 -16 -3.125 -217.75 -15.5 -2.625 -217.75 -11.25 -2.625 -217.75 -11.25 -3.125
1 16 -217.75 -13.625 0 0 1 0 0 0 -2.375 3.125 0 0 recte3.dat
1 16 -217.75 -13.375 0 0 1 0 0 0 -2.125 2.625 0 0 recte3.dat
3 16 -10.75 -15.5 2.625 -10.75 -15.5 1 -217.75 -15.5 2.625
3 16 -8.25 -15.5 -.5 8.25 -15.5 -2.625 -217.75 -15.5 -2.625
3 16 -8.25 -15.5 -.5 -217.75 -15.5 -2.625 -10.75 -15.5 0
4 16 -10.75 -15.5 1 -10.75 -15.5 0 -217.75 -15.5 -2.625 -217.75 -15.5 2.625
2 24 8.25 -15.5 -2.625 -217.75 -15.5 -2.625
2 24 -217.75 -15.5 2.625 -10.75 -15.5 2.625
4 16 -217.75 -16 3.125 -217.75 -16 -3.125 8.25 -16 -3.125 -10.75 -16 0
3 16 -10.75 -16 1 -10.75 -16 3.125 -217.75 -16 3.125
3 16 -10.75 -16 0 -10.75 -16 1 -217.75 -16 3.125
2 24 -217.75 -16 3.125 -10.75 -16 3.125
2 24 8.25 -16 -3.125 -217.75 -16 -3.125
