Unofficial File parts/s/4883s01.dat
File Header:
0 ~Duplo Car Base 2 x 6 Hook
0 Name: s\4883s01.dat
0 Author: Rene Rechthaler [Blechtaler]
0 !LDRAW_ORG Unofficial_Subpart
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2025-02-03 [Blechtaler] made from 2312 by [Philo]
Show contents
1 16 0 46 0 0 0 5 0 -1 0 -5 0 0 4-4ndis.dat
0 BFC INVERTNEXT
1 16 0 6 0 0 0 5 0 40 0 -5 0 0 4-4cylc.dat
1 16 0 5 0 0 0 9 0 41 0 -9 0 0 5-16cylo.dat
1 16 0 5 0 0 0 -9 0 41 0 -9 0 0 5-16cylo.dat
1 16 0 5 0 1 0 0 0 -1 0 0 0 -1 2-4ring9.dat
1 16 0 5 0 9 0 0 0 -1 0 0 0 9 1-16tang.dat
1 16 0 5 0 -9 0 0 0 -1 0 0 0 9 1-16tang.dat
1 16 0 0 0 10 0 0 0 5 0 0 0 -10 2-4cylc.dat
1 16 -1 0 0 11 0 0 0 5 0 0 0 9 1-16cylo.dat
1 16 1 0 0 -11 0 0 0 5 0 0 0 9 1-16cylo.dat
1 16 -1 0 0 11 0 0 0 1 0 0 0 9 1-16chrd.dat
1 16 1 0 0 -11 0 0 0 1 0 0 0 9 1-16chrd.dat
1 16 -1 5 0 11 0 0 0 -1 0 0 0 9 1-16chrd.dat
1 16 1 5 0 -11 0 0 0 -1 0 0 0 9 1-16chrd.dat
1 16 0 46 0 0 0 9 0 -1 0 -9 0 0 1-8chrd.dat
1 16 0 46 0 9 0 0 0 -1 0 0 0 -9 1-8chrd.dat
1 16 0 46 0 9 0 0 0 -1 0 0 0 9 1-16chrd.dat
1 16 0 46 0 0 0 -9 0 -1 0 -9 0 0 1-8chrd.dat
1 16 0 46 0 -9 0 0 0 -1 0 0 0 -9 1-8chrd.dat
1 16 0 46 0 -9 0 0 0 -1 0 0 0 9 1-16chrd.dat
1 16 0 0 0 0 0 9 0 32 0 9 0 0 3-16cylo.dat
1 16 0 0 0 0 0 -9 0 32 0 9 0 0 3-16cylo.dat
1 16 0 0 0 0 0 9 0 1 0 9 0 0 3-16chrd.dat
1 16 0 0 0 0 0 -9 0 1 0 9 0 0 3-16chrd.dat
1 16 8.739 2.5 3.4443 0 0 .4239 2.5 0 0 0 -1 0 rect.dat
1 16 -8.739 2.5 3.4443 0 0 .4239 2.5 0 0 0 -1 0 rect.dat
4 16 -9.1629 0 3.4443 -10 0 0 0 0 0 -8.3151 0 3.4443
4 16 0 0 9 -8.3151 0 3.4443 0 0 0 8.3151 0 3.4443
4 16 8.3151 0 3.4443 0 0 0 10 0 0 9.1629 0 3.4443
4 16 10 5 0 9 5 0 9 5 1.7901 9.1629 5 3.4443
3 16 8.3151 5 3.4443 9.1629 5 3.4443 9 5 1.7901
3 16 -9.1629 5 3.4443 -8.3151 5 3.4443 -9 5 1.7901
4 16 -10 5 0 -9.1629 5 3.4443 -9 5 1.7901 -9 5 0
1 16 3.3394 41 7.9108 0 0 2.3394 -5 0 0 0 -1 -1.0892 rect3.dat
1 16 -3.3394 41 7.9108 0 0 -2.3394 5 0 0 0 -1 -1.0892 rect3.dat
4 16 6.3639 46 -6.3639 0 46 -9 0 46 -5 5 46 -5
4 16 6.3639 46 -6.3639 5 46 -5 5 46 0 9 46 0
4 16 9 46 0 5 46 0 5 46 5 8.3151 46 3.4443
4 16 5.6788 46 6.8216 8.3151 46 3.4443 5 46 5 1 46 9
4 16 0 46 -5 0 46 -9 -6.3639 46 -6.3639 -5 46 -5
4 16 -5 46 0 -5 46 -5 -6.3639 46 -6.3639 -9 46 0
4 16 -5 46 0 -9 46 0 -8.3151 46 3.4443 -5 46 5
4 16 -5 46 5 -8.3151 46 3.4443 -5.6788 46 6.8216 -1 46 9
3 16 1 46 9 5 46 5 0 46 5
3 16 1 46 9 0 46 5 -1 46 9
3 16 -1 46 9 0 46 5 -5 46 5
Status:
Needs 2 More Votes (N)
This part has the following automated holds from the Parts Tracker
- No path of certified files to a certified or official parent in the parts folder
Current Votes:
None
Official parents and subparts
Part Events:
fixed edges and rects
2025-10-05 21:15:43
I made this one as a prim,
https://library.ldraw.org/parts/47864
Yours has a bit more geometry.
I think we shall have it as a prim in a way that serves most usecases and add the differneces in the relevant parts
https://library.ldraw.org/parts/47864
Yours has a bit more geometry.
I think we shall have it as a prim in a way that serves most usecases and add the differneces in the relevant parts
2025-10-05 21:16:08
we can change yours into a prim as it was there first
2025-10-06 10:31:35
yes, this could be used for the prim (its also made from the other duplo base and could be re-used there)
as discussed here:
https://forums.ldraw.org/thread-29106-post-58717.html#pid58717
should the rear ends of the front lip get rounded more? this one feels still too pointy...
as discussed here:
https://forums.ldraw.org/thread-29106-post-58717.html#pid58717
should the rear ends of the front lip get rounded more? this one feels still too pointy...
used 1-16cylo (differently scaled) for the rear to get a smoother end
(this also fixed the need of a comp condline i forgot earlier and improved the rects)
(this also fixed the need of a comp condline i forgot earlier and improved the rects)
one vertex slipped in the merging
2025-10-18 11:12:20
This subpart should be made into a primitive
Creative Commons Attribution License information
This part is copyright © Rene Rechthaler
Licensed under CC BY 4.0
Edits:
LDraw.org Parts Tracker,
-not 100% sure about the number
-wheels to be done (no number found)
-hitch subfiled for use in all variants (including the train bases)
