0 ~Brick 2 x 4 x 1.333 with Half Round 2 x 2 Plate Underside
0 Name: 90753.dat
0 Author: Max Martin Richter [MMR1988]
0 !LDRAW_ORG Part UPDATE 2025-03
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2013-07-21 [PTadmin] Official Update 2013-01
0 !HISTORY 2024-03-23 [OrionP] Updated ring primitives
0 !HISTORY 2024-03-24 [OrionP] Official Update 2024-02
0 !HISTORY 2025-03-06 [OrionP] Moved from u9262.dat
0 !HISTORY 2025-03-30 [OrionP] Official Update 2025-03
Show contents
0 // outside frame
1 16 0 -2.25 -15.75 0 0 35.625 2.25 0 0 0 31.5 0 box3u2p.dat
1 16 -26.875 -2.25 -15.75 0 0 8.75 2.25 0 0 0 1 0 rect3.dat
4 16 -18.125 -4.5 -15.75 -18.125 0 -15.75 -18.125 -3.5 -10.75 -18.125 -4.5 -11.75
2 24 -18.125 -4.5 -11.75 -18.125 -4.5 -15.75
2 24 -18.125 -4.5 -11.75 -18.125 -3.5 -10.75
4 16 -18.125 0 -15.75 -18.125 0 -8.75 -18.125 -3.5 -8.75 -18.125 -3.5 -10.75
2 24 -18.125 0 -15.75 -18.125 0 -8.75
2 24 -18.125 -3.5 -8.75 -18.125 -3.5 -10.75
1 16 0 -1.75 -8.75 0 0 18.125 1.75 0 0 0 1 0 rect.dat
4 16 18.125 -3.5 -10.75 18.125 -3.5 -8.75 18.125 0 -8.75 18.125 0 -15.75
2 24 18.125 0 -15.75 18.125 0 -8.75
2 24 18.125 -3.5 -8.75 18.125 -3.5 -10.75
4 16 18.125 -4.5 -11.75 18.125 -3.5 -10.75 18.125 0 -15.75 18.125 -4.5 -15.75
2 24 18.125 -4.5 -11.75 18.125 -4.5 -15.75
2 24 18.125 -4.5 -11.75 18.125 -3.5 -10.75
1 16 26.875 -2.25 -15.75 0 0 -8.75 -2.25 0 0 0 1 0 rect3.dat
0 // underside area
1 16 27.5 0 0 5.625 0 0 0 -1 0 0 0 5.625 4-4ndis.dat
1 16 -27.5 0 0 5.625 0 0 0 -1 0 0 0 5.625 4-4ndis.dat
3 16 35.625 0 15.75 33.125 0 5.625 27.5 0 5.625
3 16 33.125 0 0 33.125 0 5.625 35.625 0 15.75
4 16 35.625 0 -15.75 33.125 0 -5.625 33.125 0 0 35.625 0 15.75
4 16 18.125 0 -15.75 27.5 0 -5.625 33.125 0 -5.625 35.625 0 -15.75
4 16 18.125 0 -8.75 21.875 0 -5.625 27.5 0 -5.625 18.125 0 -15.75
3 16 21.875 0 0 21.875 0 -5.625 18.125 0 -8.75
4 16 27.5 0 5.625 21.875 0 5.625 -35.625 0 15.75 35.625 0 15.75
3 16 -27.5 0 5.625 -33.125 0 5.625 -35.625 0 15.75
3 16 -35.625 0 15.75 -33.125 0 5.625 -33.125 0 0
4 16 -35.625 0 15.75 -33.125 0 0 -33.125 0 -5.625 -35.625 0 -15.75
4 16 -35.625 0 -15.75 -33.125 0 -5.625 -27.5 0 -5.625 -18.125 0 -15.75
4 16 -18.125 0 -15.75 -27.5 0 -5.625 -21.875 0 -5.625 -18.125 0 -8.75
3 16 -18.125 0 -8.75 -21.875 0 -5.625 -21.875 0 0
3 16 -21.875 0 5.625 -27.5 0 5.625 -35.625 0 15.75
4 16 18.125 0 -8.75 -18.125 0 -8.75 -21.875 0 0 -21.875 0 5.625
3 16 -35.625 0 15.75 18.125 0 -8.75 -21.875 0 5.625
4 16 21.875 0 0 18.125 0 -8.75 -35.625 0 15.75 21.875 0 5.625
0 // +x hole
0 BFC INVERTNEXT
1 16 27.5 0 0 5.625 0 0 0 -5 0 0 0 5.625 4-4cylo.dat
1 16 27.5 -5 0 3 0 0 0 -1 0 0 0 3 4-4ring1.dat
0 BFC INVERTNEXT
1 16 27.5 -5 0 3 0 0 0 -3.75 0 0 0 3 4-4cylo.dat
1 16 27.5 -8.75 0 3 0 0 0 1 0 0 0 3 4-4ring1.dat
0 BFC INVERTNEXT
1 16 27.5 -16.25 0 5 0 0 0 7.5 0 0 0 5 4-4cylo.dat
1 16 27.5 -16.25 0 2.5 0 0 0 1 0 0 0 2.5 4-4ring2.dat
1 16 27.5 -16.25 0 0.625 0 0 0 1 0 0 0 0.625 4-4ring12.dat
1 16 27.5 -3.5 0 5.746 0 -5.745 0 -12.75 0 5.745 0 5.746 3-4cylo.dat
1 16 27.5 -4.5 0 5.745 0 5.746 0 -11.75 0 -5.746 0 5.745 1-4cylo.dat
2 24 31.625 -4.5 -6.828 33.245 -4.5 -5.745
2 24 31.625 -4.5 6.828 33.245 -4.5 5.745
2 24 31.625 -4.5 -6.828 30.625 -3.5 -7.496
2 24 31.625 -4.5 6.828 30.625 -3.5 7.496
0 // -x hole
0 BFC INVERTNEXT
1 16 -27.5 0 0 5.625 0 0 0 -5 0 0 0 5.625 4-4cylo.dat
1 16 -27.5 -5 0 3 0 0 0 -1 0 0 0 3 4-4ring1.dat
0 BFC INVERTNEXT
1 16 -27.5 -5 0 3 0 0 0 -3.75 0 0 0 3 4-4cylo.dat
1 16 -27.5 -8.75 0 3 0 0 0 1 0 0 0 3 4-4ring1.dat
0 BFC INVERTNEXT
1 16 -27.5 -16.25 0 5 0 0 0 7.5 0 0 0 5 4-4cylo.dat
1 16 -27.5 -16.25 0 2.5 0 0 0 1 0 0 0 2.5 4-4ring2.dat
1 16 -27.5 -16.25 0 0.625 0 0 0 1 0 0 0 0.625 4-4ring12.dat
1 16 -27.5 -3.5 0 -5.746 0 5.745 0 -12.75 0 -5.745 0 -5.746 3-4cylo.dat
1 16 -27.5 -4.5 0 -5.745 0 -5.746 0 -11.75 0 5.746 0 -5.745 1-4cylo.dat
2 24 -31.625 -4.5 -6.828 -33.245 -4.5 -5.745
2 24 -31.625 -4.5 6.828 -33.245 -4.5 5.745
2 24 -31.625 -4.5 -6.828 -30.625 -3.5 -7.496
2 24 -31.625 -4.5 6.828 -30.625 -3.5 7.496
0 // higher top face
4 16 18.125 -4.5 -15.75 35.625 -4.5 -15.75 31.625 -4.5 -11.75 18.125 -4.5 -11.75
4 16 35.625 -4.5 0 31.625 -4.5 -6 31.625 -4.5 -11.75 35.625 -4.5 -15.75
4 16 35.625 -4.5 15.75 31.625 -4.5 11.75 31.625 -4.5 6 35.625 -4.5 0
4 16 -18.125 -4.5 -11.75 -31.625 -4.5 -11.75 -35.625 -4.5 -15.75 -18.125 -4.5 -15.75
4 16 -35.625 -4.5 -15.75 -31.625 -4.5 -11.75 -31.625 -4.5 -6 -35.625 -4.5 0
4 16 -35.625 -4.5 0 -31.625 -4.5 6 -31.625 -4.5 11.75 -35.625 -4.5 15.75
4 16 35.625 -4.5 15.75 -35.625 -4.5 15.75 -31.625 -4.5 11.75 31.625 -4.5 11.75
1 16 0 -4.5 8.875 31.625 0 0 0 1 0 0 0 2.875 recte3.dat
2 24 -31.625 -4.5 -11.75 -18.125 -4.5 -11.75
2 24 18.125 -4.5 -11.75 31.625 -4.5 -11.75
2 24 31.625 -4.5 -11.75 31.625 -4.5 -6
2 24 -31.625 -4.5 -11.75 -31.625 -4.5 -6
0 // top slope
4 16 -30.625 -3.5 10.75 30.625 -3.5 10.75 31.625 -4.5 11.75 -31.625 -4.5 11.75
4 16 -31.625 -4.5 -11.75 -18.125 -4.5 -11.75 -18.125 -3.5 -10.75 -30.625 -3.5 -10.75
4 16 30.625 -3.5 -10.75 18.125 -3.5 -10.75 18.125 -4.5 -11.75 31.625 -4.5 -11.75
4 16 30.625 -3.5 -10.75 31.625 -4.5 -11.75 31.625 -4.5 -6 30.625 -3.5 -6
4 16 30.625 -3.5 6 31.625 -4.5 6 31.625 -4.5 11.75 30.625 -3.5 10.75
4 16 -30.625 -3.5 -6 -31.625 -4.5 -6 -31.625 -4.5 -11.75 -30.625 -3.5 -10.75
4 16 -30.625 -3.5 10.75 -31.625 -4.5 11.75 -31.625 -4.5 6 -30.625 -3.5 6
1 16 0 -3.5 8.375 30.625 0 0 0 1 0 0 0 2.375 recte3.dat
2 24 -30.625 -3.5 -10.75 -18.125 -3.5 -10.75
2 24 18.125 -3.5 -10.75 30.625 -3.5 -10.75
2 24 30.625 -3.5 -10.75 30.625 -3.5 -6
2 24 -30.625 -3.5 -10.75 -30.625 -3.5 -6
2 24 -31.625 -4.5 -11.75 -30.625 -3.5 -10.75
2 24 31.625 -4.5 -11.75 30.625 -3.5 -10.75
2 24 -31.625 -4.5 11.75 -30.625 -3.5 10.75
2 24 31.625 -4.5 11.75 30.625 -3.5 10.75
0 // lower top face
4 16 24.5 -3.5 6.125 30.625 -3.5 6 30.625 -3.5 10.75 -30.625 -3.5 10.75
4 16 19.375 -3.5 0 24.5 -3.5 6.125 -30.625 -3.5 10.75 -27.5 -3.5 8.125
4 16 27.5 -3.5 -8.125 19.375 -3.5 0 -27.5 -3.5 8.125 -19.375 -3.5 0
3 16 -30.625 -3.5 10.75 -30.625 -3.5 6 -27.5 -3.5 8.125
4 16 -18.125 -3.5 -8.75 18.125 -3.5 -8.75 27.5 -3.5 -8.125 -19.375 -3.5 0
3 16 30.625 -3.5 -10.75 30.625 -3.5 -6 27.5 -3.5 -8.125
4 16 18.125 -3.5 -8.75 18.125 -3.5 -10.75 30.625 -3.5 -10.75 27.5 -3.5 -8.125
4 16 -18.125 -3.5 -8.75 -19.375 -3.5 0 -24.5 -3.5 -6.125 -18.125 -3.5 -10.75
4 16 -24.5 -3.5 -6.125 -30.625 -3.5 -6 -30.625 -3.5 -10.75 -18.125 -3.5 -10.75
