0 Technic Link  5L
0 Name: 30397.dat
0 Author: John Riley [jriley]
0 !LDRAW_ORG Part UPDATE 2023-02
0 !LICENSE Licensed under CC BY 2.0 and CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2004-04-22 [PTadmin] Official Update 2004-02
0 !HISTORY 2007-06-09 [PTadmin] Header formatted for Contributor Agreement
0 !HISTORY 2008-07-01 [PTadmin] Official Update 2008-01
0 !HISTORY 2020-06-04 [Sirio] Updated the use of primitives: removed ringr.dat or ringrr.dat, introduced use of 2-4cylo.dat and 4-4ring8.dat, substituted some quads with rects
0 !HISTORY 2023-04-17 [OrionP] Official Update 2023-02

Show contents

0 // Primitives
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\6247s01.dat
1 16 0 0 80 1 0 0 0 1 0 0 0 -1 s\6247s01.dat

1 16 -8 0 40 0 -1 0 0 0 4 30 0 0 box3u8p.dat
1 16 8 0 40 0 1 0 0 0 4 30 0 0 box3u8p.dat
1 16 0 3 40 0 0 8 0 -1 0 30 0 0 rect2p.dat
1 16 0 -3 40 0 0 8 0 1 0 30 0 0 rect2p.dat
0 // Faces
4 16 -8 3 10 -8 4 10 -8 4 70 -8 3 70
4 16 8 3 10 8 3 70 8 4 70 8 4 10
4 16 -8 -3 10 -8 -3 70 -8 -4 70 -8 -4 10
4 16 8 -3 10 8 -4 10 8 -4 70 8 -3 70

Status:

Official

Unofficial parents

Part Events:

Archived Part Events:

Massimo Maso [Sirio]

initially submitted the part.

2020-06-18 04:40:04

Massimo Maso [Sirio]

submitted a new version of the part.

2020-07-23 22:10:02

Created a subpart, which I considered a primitive, even if it is currently used only in 6247 and 30397.
This allows you to eliminate all T-juntions and the code of the single part is greatly reduced.
For the primitive I considered a little more than the tangency to the main cylinder which allows to simplify the insertion of the same in the main part (face connections and lengths), slightly increases the number of faces in the primitive.
Intersections are calculated with a 48-sided cylinder. There are also some extra faces that give a more rounded overall shape, but they could be eliminated leaving a 16-sided geometry in that area.
