Magnet Holder 2 x 3 Technic Brick
File Header:
0 Magnet Holder 2 x 3 Technic Brick 0 Name: 2607b.dat 0 Author: Rene Rechthaler [Blechtaler] 0 !LDRAW_ORG Part UPDATE 2025-06 0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt 0 !HELP place magnet 2959bc01 at 0 9 -31.25 0 !HELP 1 16 0 0 0 1 0 0 0 1 0 0 0 1 2607b.dat 0 !HELP 1 16 0 9 -31.25 1 0 0 0 1 0 0 0 1 2959bc01.dat (horizontal) 0 !HELP 1 0 0 9 -31.25 1 0 0 0 0 1 0 1 0 2959bc01.dat (vertical) 0 BFC CERTIFY CCW 0 !KEYWORDS BrickLink 2607, Rebrickable 2607 0 !HISTORY 2025-03-23 [Blechtaler] reworked to fit the magnet better 0 !HISTORY 2025-06-26 [OrionP] Official Update 2025-06
Show contents
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\2607bs01.dat 1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\2607bs01.dat 0 // seam 3 16 0 0 -6 -15 0 -10 15 0 -10 3 16 0 0 6 10 0 10 -10 0 10 2 24 -15 0 -10 15 0 -10 2 24 -10 0 10 10 0 10 3 16 0 2 -10 15 0 -10 -15 0 -10 3 16 0 18 -10 -19 24 -10 19 24 -10 3 16 -10 0 10 10 0 10 0 2 10 3 16 10 24 10 -10 24 10 0 18 10 4 16 19 24 -10 -19 24 -10 -6 24 -6 6 24 -6 4 16 -10 24 10 10 24 10 6 24 6 -6 24 6 2 24 -19 24 -10 19 24 -10 2 24 10 24 10 -10 24 10 3 16 6 18 -6 -6 18 -6 0 18 -4 3 16 -6 18 6 6 18 6 0 18 4 0 // top stud 1 16 0 0 0 1 0 0 0 1 0 0 0 1 stud2a.dat 1 16 0 0 0 6 0 0 0 1 0 0 0 6 4-4edge.dat 1 16 0 0 0 6 0 0 0 1 0 0 0 6 4-4ndis.dat 0 // intersection 1 16 0 10 10 1 0 0 0 0 1 0 -1 0 peghole.dat 1 16 0 10 -10 1 0 0 0 0 -1 0 1 0 peghole.dat 1 16 0 10 10 -8 0 0 0 0 8 0 -1 0 4-4ndis.dat 1 16 0 10 -10 8 0 0 0 0 8 0 1 0 4-4ndis.dat 0 BFC INVERTNEXT 1 16 0 0 0 4 0 0 0 4 0 0 0 4 4-4cyli.dat 0 BFC INVERTNEXT 1 16 0 16 0 4 0 0 0 2 0 0 0 4 4-4cyli.dat 0 BFC INVERTNEXT 1 16 0 10 4 6 0 0 0 0 6 0 4 0 4-4cyli.dat 0 BFC INVERTNEXT 1 16 0 10 -4 6 0 0 0 0 6 0 -4 0 4-4cyli.dat 0 BFC INVERTNEXT 1 16 0 18 0 6 0 0 0 6 0 0 0 6 box4.dat 1 16 0 18 0 4 0 0 0 -1 0 0 0 4 4-4ndis.dat 1 16 0 18 0 4 0 0 0 1 0 0 0 4 4-4edge.dat
Status:
Official Official
Unofficial parents
Part Events:
Archived Part Events:
Rene Rechthaler [Blechtaler]
Part Header Editor
initially submitted the part.
2025-03-23 15:58:27
rework (the arm subfile 2609s02 doesnt fit yet, it has to be fixed)
Rene Rechthaler [Blechtaler]
Part Header Editor
made the following comment.
2025-03-23 17:30:15
should this include the small reinfocements on the inside of the arms?
Chris Böhnke [KnightOfTarenta]
Part Header Editor
posted a vote of Hold.
2025-03-23 23:36:30
The arm sub-file should be the same across 2609a, 2609c and this I'd say - geometry on the real parts is perfectly identical.

And yes - please include the reinforcements, they are even in LDD.
Rene Rechthaler [Blechtaler]
Part Header Editor
submitted a new version of the part.
2025-03-24 11:16:06
thanks for the reminder of the LDD part...
used the DB part to copy the reinforcements from there.
should it get subfiled in half?
Willy Tschager [Holly-Wood]
Senior Part Reviewer
posted a vote of Hold.
2025-03-24 15:24:43
* The clip is identical to 2609a (which has to be corrected first).
Rene Rechthaler [Blechtaler]
Part Header Editor
made the following comment.
2025-03-24 16:32:26
yes I know that the subfile is now wrong, but that isnt mine and ejboer is active
even the LDD data shows the arms at 5x18LDU
Willy Tschager [Holly-Wood]
Senior Part Reviewer
made the following comment.
2025-03-24 16:40:49
2609a is an official. Fix it right away.
Rene Rechthaler [Blechtaler]
Part Header Editor
made the following comment.
2025-03-24 19:11:25
no, the arm subfile in question here is 2609s02, that part isnt mine and the author is active (not online today but was recently)
already slapped a hold on it with the correct dimensions
Rene Rechthaler [Blechtaler]
Part Header Editor
made the following comment.
2025-03-26 22:20:00
arm subpart is corrected, should I add shortcuts with magnet?
Magnus Forsberg [MagFors]
Part Library Admin
made the following comment.
2025-03-29 21:21:00
If this is a new version made because 2607 is incorrect, I think the old history should be removed.
And you will be the author of this file.

I question the position of the rotation point of the magnet and the size of the magnet.
When assembled in LDD they line up prefectly, 80 ldu apart, and the magnets touch.
Magnus Forsberg [MagFors]
Part Library Admin
posted a vote of Hold.
2025-03-29 21:21:14
see above
Rene Rechthaler [Blechtaler]
Part Header Editor
made the following comment.
2025-03-29 22:03:13
LDD data isnt 100% correct...
i measured my assemblies and they are all at 19.8mm (39.5 LDU)
(ok there might be play)
also, the single part is 18.4mm (46 LDU)
should I upload the assemblies as shortcuts?
guess you are correct with the header.
Rene Rechthaler [Blechtaler]
Part Header Editor
made the following comment.
2025-03-29 22:20:20
sorry, typo: magnet sideways 19.8mm (49.5 LDU), two holders with magnets facing each other 39.6 (99 LDU)
magnets stacked: 32.6mm (81.5 LDU) across both holders
-> looks like the position now is correct
Chris Böhnke [KnightOfTarenta]
Part Header Editor
made the following comment.
2025-03-29 22:25:06
I tend to say Magnus is right.
Tested it with 2 real ones and the magnets touch seemingly perfect when the holders are placed 5 studs away.
Rene Rechthaler [Blechtaler]
Part Header Editor
made the following comment.
2025-03-29 22:32:30
looks like there is both play in the magnet-holder joint as in the magnet-ring joint (the magnet seems to slide a bit)
Chris Böhnke [KnightOfTarenta]
Part Header Editor
made the following comment.
2025-03-29 22:50:28
Yes; I noticed the slide in the ring too. Also almost all my magnets seem to be longer than the plastic ring, which is also reflected in LDD.
Rene Rechthaler [Blechtaler]
Part Header Editor
submitted a new version of the part.
2025-03-29 23:11:20
took ownership, removed the old history
also made the arms 0.5 LDU longer, the contact point is now at exactly 40LDU
Rene Rechthaler [Blechtaler]
Part Header Editor
made the following comment.
2025-03-29 23:12:50
"Also almost all my magnets seem to be longer than the plastic ring"
-> should I make the housing thinner? the magnet should stay at L17.5, the housing could go down to 17
Rene Rechthaler [Blechtaler]
Part Header Editor
submitted a new version of the part.
2025-03-30 09:22:19
cut in half, added !HELP for the magnet
Willy Tschager [Holly-Wood]
Senior Part Reviewer
posted a vote of Certify.
2025-05-17 18:21:01
Chris Böhnke [KnightOfTarenta]
Part Header Editor
posted a vote of Certify.
2025-05-28 08:27:51
Magnus Forsberg [MagFors]
Part Library Admin
edited the part header.
2025-06-20 21:19:26
Header Edits

help:
0 !HELP place magnet 2959bc01 at 0 9 -31.25
0 !HELP 1 16 0 0 0 1 0 0 0 1 0 0 0 1 2607b.dat
0 !HELP 1 16 0 9 -31.25 1 0 0 0 1 0 0 0 1 2959bc01.dat
to
0 !HELP place magnet 2959bc01 at 0 9 -31.25
0 !HELP 1 16 0 0 0 1 0 0 0 1 0 0 0 1 2607b.dat
0 !HELP 1 16 0 9 -31.25 1 0 0 0 1 0 0 0 1 2959bc01.dat (horizontal)
0 !HELP 1 0 0 9 -31.25 1 0 0 0 0 1 0 1 0 2959bc01.dat (vertical)

Comment:
extended Help info
Magnus Forsberg [MagFors]
Part Library Admin
edited the part header.
2025-06-21 07:18:51
Header Edits

description:
Magnet Holder 2 x 3
to
Magnet Holder 2 x 3 Technic Brick

Magnus Forsberg [MagFors]
Part Library Admin
posted a vote of Admin Review.
2025-06-21 07:20:24
Orion Pobursky [OrionP]
Part Library Admin
2025-06-26 01:28:24
Release 2025-06
