File Detail parts/s/2439s01.dat

Unofficial File parts/s/2439s01.dat

File Header:

0 ~Container  2 x  2 Rubbish Bin - Quarter
0 Name: s\2439s01.dat
0 Author: Peter Blomberg [WUIt]
0 !LDRAW_ORG Unofficial_Subpart
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2025-04-22 [WUIt] Subfiled from 2439 by Bernd Broich [bbroich], Removed T-junctions, added cond lines, and improved use of prims
0 !HISTORY 2025-04-23 [Blechtaler] cut to a quarter, used more prims

Show contents

0 // Top
1 16 0 0 0 17 0 0 0 1 0 0 0 -17 1-4tang.dat
4 16 3.3813 0 -17 0 0 -17 1 0 -18.935 4.9172 0 -18.352
4 16 3.3813 0 -17 4.9172 0 -18.352 8.601 0 -16.898 6.5059 0 -15.7063
4 16 10.333 0 -15.898 9.6305 0 -14.4126 6.5059 0 -15.7063 8.601 0 -16.898
4 16 12.0207 0 -12.0207 9.6305 0 -14.4126 10.333 0 -15.898 13.435 0 -13.435
4 16 14.4126 0 -9.6305 12.0207 0 -12.0207 13.435 0 -13.435 15.898 0 -10.333
4 16 15.898 0 -10.333 16.898 0 -8.601 15.7063 0 -6.5059 14.4126 0 -9.6305
4 16 16.898 0 -8.601 17.925 0 -6 17 0 -3.3813 15.7063 0 -6.5059
3 16 17.925 0 -6 18.806 0 -6 17 0 -3.3813
4 16 17 0 -3.3813 18.806 0 -6 20 0 0 17 0 0

0 // Bottom
3 16 13.435 43 -13.435 4.788 43 -16 16 43 -4.788
4 16 1 43 -18.935 0 43 -18.5 4.788 43 -17.869 4.9172 43 -18.352
4 16 8.601 43 -16.898 4.9172 43 -18.352 4.788 43 -17.869 4.788 43 -16
4 16 10.333 43 -15.898 8.601 43 -16.898 4.788 43 -16 13.435 43 -13.435
4 16 16.898 43 -8.601 15.898 43 -10.334 13.435 43 -13.435 16 43 -4.788
4 16 16.898 43 -8.601 16 43 -4.788 17.869 43 -4.788 18.352 43 -4.9172
4 16 18.352 43 -4.9172 17.869 43 -4.788 18.5 43 0 18.935 43 -1

0 // Bottom fins
1 16 2.394 45.5 -18.1845 -2.394 -1 0 0 0 2.5 -.3155 0 0 rect2p.dat
1 16 18.1845 45.5 -2.394 .3155 -1 0 0 0 -2.5 2.394 0 0 rect2p.dat
3 16 18.5 48 0 17.869 48 -4.788 16 48 -4.788
3 16 4.788 48 -17.869 0 48 -18.5 4.788 48 -16
5 24 0 43 -18.5 0 48 -18.5 4.788 43 -17.869 -1 43 -18.5
5 24 18.5 43 0 18.5 48 0 17.869 43 -4.788 18.5 43 1

0 // Outer Cylinder
1 16 2.9586 21.5 -18.6435 -1.9586 -1 0 0 0 21.5 -.2915 0 0 rect2p.dat
1 16 6.7591 21.5 -17.625 -1.8419 -1 0 0 0 21.5 -.727 0 0 rect2p.dat
1 16 9.467 21.5 -16.398 .866 .283 0 0 0 21.5 .5 -.489 0 box5-2p.dat
1 16 11.884 21.5 -14.6665 -1.551 -1 0 0 0 21.5 -1.2315 0 0 rect2p.dat
4 16 14.972 7 -11.5 15.898 7 -10.333 15.898 0 -10.333 13.435 0 -13.435
4 16 14.972 12 -11.5 14.972 7 -11.5 13.435 0 -13.435 13.435 43 -13.435
4 16 15.898 12 -10.334 14.972 12 -11.5 13.435 43 -13.435 15.898 43 -10.334
2 24 15.898 0 -10.333 13.435 0 -13.435
2 24 13.435 43 -13.435 15.898 43 -10.334
1 16 16.398 3.5 -9.467 .5 .489 0 0 0 -3.5 .866 -.283 0 box4-2p.dat
1 16 16.398 27.5 -9.467 .5 .489 0 0 0 15.5 .866 -.283 0 box4-2p.dat
1 16 17.4115 3.5 -7.3005 0 -1 .5135 3.5 0 0 0 0 1.3005 rect3.dat
1 16 17.625 27.5 -6.7591 .727 -1 0 0 0 15.5 1.8419 0 0 rect2p.dat
1 16 18.6435 27.5 -2.9586 .2915 -1 0 0 0 15.5 1.9586 0 0 rect2p.dat
5 24 4.9172 0 -18.352 4.9172 43 -18.352 1 0 -18.935 8.601 0 -16.898
5 24 13.435 0 -13.435 13.435 43 -13.435 15.898 0 -10.333 10.333 0 -15.898
5 24 18.352 12 -4.9172 18.352 43 -4.9172 16.898 12 -8.601 18.935 12 -1

0 // Side Connector
2 24 15.898 12 -10.334 14.972 12 -11.5
2 24 15.898 7 -10.333 14.972 7 -11.5
2 24 17.925 7 -6 21 7 -6
2 24 24.304 11.031 -6 24 9.5 -6
2 24 24.304 7.969 -6 24 9.5 -6
2 24 24.952 12 -6 24.304 11.031 -6
2 24 24.952 12 -7 24.952 12 -6
2 24 24.952 12 -7 27 12 -7
2 24 24.952 7 -6 24.304 7.969 -6
2 24 24.952 7 -7 24.952 7 -6
2 24 27 7 -7 24.952 7 -7
3 16 16.387 12 -10.616 14.972 12 -11.5 15.898 12 -10.334
3 16 15.898 7 -10.333 14.972 7 -11.5 16.387 7 -10.616
3 16 24 12 -9 14.972 12 -11.5 16.387 12 -10.616
3 16 16.387 7 -10.616 14.972 7 -11.5 24 7 -9
3 16 24 12 -9 24.952 12 -7 27 12 -7
3 16 27 7 -7 24.952 7 -7 24 7 -9
4 16 16.898 7 -8.601 17.387 7 -8.884 21 7 -6 17.925 7 -6
1 16 19.486 9.5 -10.25 0 -1 -4.514 -2.5 0 0 0 0 -1.25 rect3.dat
4 16 18.352 12 -4.9172 18.935 12 -1 19.5 12 -1 21 12 -6
1 16 25.5 9.5 -8 0 -1 1.5 2.5 0 0 0 0 1 rect.dat
4 16 21 7 -6 17.387 7 -8.884 16.387 7 -10.616 24 7 -9
4 16 21 7 -6 24 7 -9 24.952 7 -7 24.952 7 -6
4 16 16.898 12 -8.601 18.352 12 -4.9172 21 12 -6 17.387 12 -8.884
4 16 24.952 12 -6 24.952 12 -7 24 12 -9 21 12 -6
4 16 21 12 -6 24 12 -9 16.387 12 -10.616 17.387 12 -8.884
3 16 24.952 12 -6 21 12 -6 24.304 11.031 -6
3 16 24.304 11.031 -6 21 12 -6 24 9.5 -6
3 16 24 9.5 -6 21 12 -6 21 7 -6
3 16 24 9.5 -6 21 7 -6 24.304 7.969 -6
3 16 24.304 7.969 -6 21 7 -6 24.952 7 -6
2 24 24.952 7 -6 21 7 -6
2 24 24.952 12 -6 21 12 -6

0 // Top near handle
1 16 19.403 -1 -3 0 1 -.597 1 0 0 0 0 -3 rect3.dat
2 24 17.925 0 -6 18.806 0 -6
2 24 18.806 -2 -6 21 -2 -6
3 16 21 -2 -6 20 -2 0 18.806 -2 -6
4 16 17.925 0 -6 17.925 7 -6 21 7 -6 18.806 0 -6
4 16 18.806 -2 -6 18.806 0 -6 21 7 -6 21 -2 -6
5 24 20 -2 0 20 0 0 18.806 -2 -6 20 -2 1

Status:

Needs More Votes (N)

This part has the following automated holds from the Parts Tracker

No path of certified files to a certified or official parent in the parts folder

Current Votes:

None

Official parents and subparts

Part Events:

Peter Blomberg [WUIt]

initially submitted the part.

2025-04-22 09:15:09

Subparted half. Removed T-junctions, improved prims around handle.

Rene Rechthaler [Blechtaler]

made the following comment.

2025-04-22 10:05:07

you could put the handle in the main file and reduce this to a quarter
maybe even put a 1-4tang at the top and an inverted 4-4cylc in the main part.
(then the inside scales)

Magnus Forsberg [MagFors]

posted a vote of Hold.

2025-04-22 17:54:51

Missing many condlines.
This is a new file? The old history should stay in the main file and is not needed here.

Rene Rechthaler [Blechtaler]

made the following comment.

2025-04-22 17:59:46

the condline issue can be reduced by using a cylc prim for the inside

Peter Blomberg [WUIt]

submitted a new version of the part.

2025-04-22 20:03:00

Changed inner cyl to prim as suggested. Used standard 16-res, but it clashes a bit with the 24-fold symmetry at the top. Would 64-hires be overkill?
Removed history from subfile as instructed.

Rene Rechthaler [Blechtaler]

made the following comment.

2025-04-22 20:25:39

standard res is enough for the inside, should still get cut down to a quarter (put the seam rects in the main file)

Peter Blomberg [WUIt]

submitted a new version of the part.

2025-04-22 21:47:29

Reverted to 24-fold inner cylinder to honor original authors design. I also find it pleasing my eye more than the 16-fold standard res cylinder.
Added missing cond lines to inner cyl and the small fin at the top. Removed more T-junctions. Added some box and rect prims.
Changed date as it is now over midnight.
I'm now done with the part (assuming I haven't introduced any direct errors). As Orion points out, anyone may edit.

Rene Rechthaler [Blechtaler]

posted a vote of Hold.

2025-04-22 22:06:24

microgaps inside

Gerald Lasser [GeraldLasser]

made the following comment.

2025-04-22 22:26:07

could use 48 prims then those gaps can be avoided

also splititng into quarters is possible

Peter Blomberg [WUIt]

submitted a new version of the part.

2025-04-22 22:30:17

Removed microgaps inside, outside, top and bottom. Removed duplicated cond lines on outer cyl.

Rene Rechthaler [Blechtaler]

made the following comment.

2025-04-22 22:30:39

ok I try it tomorrow...

Rene Rechthaler [Blechtaler]

submitted a new version of the part.

2025-04-23 10:36:08

cut to a quarter, used box prims for the ridges

Peter Blomberg [WUIt]

edited the part header.

2025-04-30 20:35:00

Header Edits

description:
~Container 2 x 2 Rubbish Bin (Quarter)
to
~Container 2 x 2 Rubbish Bin - Quarter

Comment:
Changed parenthesis to dash in description
