Unofficial File p/48/3-16cyls.dat
File Header:
0 Hi-Res Cylinder Sloped 0.1875
0 Name: 48\3-16cyls.dat
0 Author: Peter Blomberg [WUIt]
0 !LDRAW_ORG Unofficial_48_Primitive
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
Show contents
3 16 1 0 0 0.9914 0.0086 0.1305 0.9914 0 0.1305
4 16 0.9914 0.0086 0.1305 0.9659 0.0341 0.2588 0.9659 0 0.2588 0.9914 0 0.1305
4 16 0.9659 0.0341 0.2588 0.9239 0.0761 0.3827 0.9239 0 0.3827 0.9659 0 0.2588
4 16 0.9239 0.0761 0.3827 0.866 0.1340 0.5 0.866 0 0.5 0.9239 0 0.3827
4 16 0.866 0.1340 0.5 0.7934 0.2066 0.6088 0.7934 0 0.6088 0.866 0 0.5
4 16 0.7934 0.2066 0.6088 0.7071 0.2929 0.7071 0.7071 0 0.7071 0.7934 0 0.6088
4 16 0.7071 0.2929 0.7071 0.6088 0.3912 0.7934 0.6088 0 0.7934 0.7071 0 0.7071
4 16 0.6088 0.3912 0.7934 0.5 0.5 0.866 0.5 0 0.866 0.6088 0 0.7934
4 16 0.5 0.5 0.866 0.3827 0.6173 0.9239 0.3827 0 0.9239 0.5 0 0.866
5 24 0.9914 0 0.1305 0.9914 0.0086 0.1305 1 0 0 0.9659 0 0.2588
5 24 0.9659 0 0.2588 0.9659 0.0341 0.2588 0.9914 0 0.1305 0.9239 0 0.3827
5 24 0.9239 0 0.3827 0.9239 0.0761 0.3827 0.9659 0 0.2588 0.866 0 0.5
5 24 0.866 0 0.5 0.866 0.1340 0.5 0.9239 0 0.3827 0.7934 0 0.6088
5 24 0.7934 0 0.6088 0.7934 0.2066 0.6088 0.866 0 0.5 0.7071 0 0.7071
5 24 0.7071 0 0.7071 0.7071 0.2929 0.7071 0.7934 0 0.6088 0.6088 0 0.7934
5 24 0.6088 0 0.7934 0.6088 0.3912 0.7934 0.7071 0 0.7071 0.5 0 0.866
5 24 0.5 0 0.866 0.5 0.5 0.866 0.6088 0 0.7934 0.3827 0 0.9239
5 24 .3827 0 .9239 .3827 0.6173 .9239 .5 0 .866 .2611 0 .9743
Status:
Needs 1 More Vote (CN)
This part has the following automated holds from the Parts Tracker
- No path of certified files to a certified or official parent in the parts folder
This part has the following errors
-
Numbers cannot have trailing zerosLine text: 4 16 0.9239 0.0761 0.3827 0.866 0.1340 0.5 0.866 0 0.5 0.9239 0 0.3827
-
Numbers cannot have trailing zerosLine text: 4 16 0.866 0.1340 0.5 0.7934 0.2066 0.6088 0.7934 0 0.6088 0.866 0 0.5
-
Numbers cannot have trailing zerosLine text: 5 24 0.866 0 0.5 0.866 0.1340 0.5 0.9239 0 0.3827 0.7934 0 0.6088
This part has the following warnings
- Number in description may need a leading space
Current Votes:
| User | Vote |
|---|---|
| Holly-Wood | Certify |
Official parents and subparts
Part Events:
2025-05-08 13:28:25
2025-05-24 12:34:46
Shouldn't the last condline have a controlpoint on the tangental plane?
Yes, how can that be fixed?
Corrected last cond line to tangential as required.
2025-05-25 07:54:51
Do any of the files that use this primitive need to be changed?
Complementary condlines?
Complementary condlines?
2025-05-25 08:26:46
Only one part uses this primitive and that part is on the tracker.
2025-10-04 12:31:38
2026-01-18 11:34:04
0.1340 causes an error (3x, 2 quads one cond)
