File Detail parts/s/69182s03.dat

Official File parts/s/69182s03.dat

~Die 6 Sides 3 x 3 x 3 with Loop on One Edge - Rubber Part 1/12th

File Header:

0 ~Die  6 Sides  3 x  3 x  3 with Loop on One Edge - Rubber Part 1/12th
0 Name: s\69182s03.dat
0 Author: Gerald Lasser [GeraldLasser]
0 !LDRAW_ORG Subpart UPDATE 2025-06
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2025-06-26 [OrionP] Official Update 2025-06

Show contents

2 24 29.75 0 -29.75 29.75 0 29.75
4 16 29.75 0 29.75 27.5 0 27.5 27.5 0 -27.5 29.75 0 -29.75
3 16 29.75 0 29.75 38.9008 -9.1508 22.3125 38.25 -8.5 29.75
4 16 39.5871 -9.8371 7.4375 39.297 -9.547 14.875 38.9008 -9.1508 22.3125 29.75 0 29.75
4 16 39.5871 -9.8371 -7.4375 39.75 -10 0 39.5871 -9.8371 7.4375 29.75 0 29.75
4 16 38.25 -8.5 -29.75 38.9008 -9.1508 -22.3125 29.75 0 29.75 29.75 0 -29.75
4 16 38.9008 -9.1508 -22.3125 39.297 -9.547 -14.875 39.5871 -9.8371 -7.4375 29.75 0 29.75
3 16 38.25 -8.5 29.75 37.4134 -7.6634 37.4134 29.75 0 29.75
3 16 38.25 -8.5 -29.75 29.75 0 -29.75 37.4134 -7.6634 -37.4134
2 24 38.25 -8.5 -29.75 37.4134 -7.6634 -37.4134
2 24 38.25 -8.5 -29.75 38.9008 -9.1508 -22.3125
2 24 38.9008 -9.1508 -22.3125 39.297 -9.547 -14.875
2 24 39.297 -9.547 -14.875 39.5871 -9.8371 -7.4375
2 24 39.5871 -9.8371 -7.4375 39.75 -10 0
2 24 39.75 -10 0 39.5871 -9.8371 7.4375
2 24 39.5871 -9.8371 7.4375 39.297 -9.547 14.875
2 24 39.297 -9.547 14.875 38.9008 -9.1508 22.3125
2 24 38.9008 -9.1508 22.3125 38.25 -8.5 29.75
2 24 38.25 -8.5 29.75 37.4134 -7.6634 37.4134
4 16 41.5871 -7.8371 7.4375 41.75 -8 0 41.5871 -7.8371 -7.4375 31.75 2 29.75
3 16 40.25 -6.5 -29.75 39.4134 -5.6634 -37.4134 31.75 2 -29.75
3 16 40.25 -6.5 29.75 31.75 2 29.75 39.4134 -5.6634 37.4134
4 16 41.5871 -7.8371 -7.4375 41.297 -7.547 -14.875 40.9008 -7.1508 -22.3125 31.75 2 29.75
3 16 40.25 -6.5 29.75 40.9008 -7.1508 22.3125 31.75 2 29.75
4 16 40.9008 -7.1508 22.3125 41.297 -7.547 14.875 41.5871 -7.8371 7.4375 31.75 2 29.75
4 16 31.75 2 -29.75 31.75 4.25 -27.5 31.75 4.25 27.5 31.75 2 29.75
4 16 31.75 2 29.75 40.9008 -7.1508 -22.3125 40.25 -6.5 -29.75 31.75 2 -29.75
2 24 31.75 2 29.75 31.75 2 -29.75
2 24 39.4134 -5.6634 -37.4134 40.25 -6.5 -29.75
2 24 40.25 -6.5 -29.75 40.9008 -7.1508 -22.3125
2 24 40.9008 -7.1508 -22.3125 41.297 -7.547 -14.875
2 24 41.297 -7.547 -14.875 41.5871 -7.8371 -7.4375
2 24 41.5871 -7.8371 -7.4375 41.75 -8 0
2 24 41.75 -8 0 41.5871 -7.8371 7.4375
2 24 41.5871 -7.8371 7.4375 41.297 -7.547 14.875
2 24 41.297 -7.547 14.875 40.9008 -7.1508 22.3125
2 24 40.9008 -7.1508 22.3125 40.25 -6.5 29.75
2 24 40.25 -6.5 29.75 39.4134 -5.6634 37.4134
4 16 37.4134 -7.6634 37.4134 38.25 -8.5 29.75 40.25 -6.5 29.75 39.4134 -5.6634 37.4134
4 16 40.25 -6.5 29.75 38.25 -8.5 29.75 38.9008 -9.1508 22.3125 40.9008 -7.1508 22.3125
4 16 40.9008 -7.1508 22.3125 38.9008 -9.1508 22.3125 39.297 -9.547 14.875 41.297 -7.547 14.875
4 16 41.297 -7.547 14.875 39.297 -9.547 14.875 39.5871 -9.8371 7.4375 41.5871 -7.8371 7.4375
4 16 41.5871 -7.8371 7.4375 39.5871 -9.8371 7.4375 39.75 -10 0 41.75 -8 0
4 16 41.75 -8 0 39.75 -10 0 39.5871 -9.8371 -7.4375 41.5871 -7.8371 -7.4375
4 16 41.5871 -7.8371 -7.4375 39.5871 -9.8371 -7.4375 39.297 -9.547 -14.875 41.297 -7.547 -14.875
4 16 41.297 -7.547 -14.875 39.297 -9.547 -14.875 38.9008 -9.1508 -22.3125 40.9008 -7.1508 -22.3125
4 16 40.9008 -7.1508 -22.3125 38.9008 -9.1508 -22.3125 38.25 -8.5 -29.75 40.25 -6.5 -29.75
4 16 40.25 -6.5 -29.75 38.25 -8.5 -29.75 37.4134 -7.6634 -37.4134 39.4134 -5.6634 -37.4134
5 24 39.5871 -9.8371 7.4375 41.5871 -7.8371 7.4375 41.297 -7.547 14.875 39.75 -10 0
5 24 40.25 -6.5 -29.75 38.25 -8.5 -29.75 37.4134 -7.6634 -37.4134 40.9008 -7.1508 -22.3125
5 24 39.4134 -5.6634 -37.4134 37.4134 -7.6634 -37.4134 40.25 -6.5 -29.75 37.4134 -5.6634 -39.4134
5 24 38.9008 -9.1508 -22.3125 40.9008 -7.1508 -22.3125 41.297 -7.547 -14.875 38.25 -8.5 -29.75
5 24 41.297 -7.547 -14.875 39.297 -9.547 -14.875 38.9008 -9.1508 -22.3125 41.5871 -7.8371 -7.4375
5 24 41.75 -8 0 39.75 -10 0 39.5871 -9.8371 -7.4375 41.5871 -7.8371 7.4375
5 24 40.25 -6.5 29.75 38.25 -8.5 29.75 39.4134 -5.6634 37.4134 38.9008 -9.1508 22.3125
5 24 38.9008 -9.1508 22.3125 40.9008 -7.1508 22.3125 40.25 -6.5 29.75 39.297 -9.547 14.875
5 24 41.297 -7.547 14.875 39.297 -9.547 14.875 40.9008 -7.1508 22.3125 39.5871 -9.8371 7.4375
5 24 37.4134 -7.6634 37.4134 39.4134 -5.6634 37.4134 37.4134 -5.6634 39.4134 38.25 -8.5 29.75
5 24 39.5871 -9.8371 -7.4375 41.5871 -7.8371 -7.4375 39.297 -9.547 -14.875 41.75 -8 0

Status:

Official
