~Car Base 4 x 14 x 1 with Tow Ball Socket - One Half

File Header:

0 ~Car Base  4 x 14 x  1 with Tow Ball Socket - One Half
0 Name: s\30842s01.dat
0 Author: Massimo Maso [Sirio]
0 !LDRAW_ORG Unofficial_Subpart
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW
