File Detail parts/4710c.dat

Unofficial File parts/4710c.dat

Part Attributes:

~Electric Switch: Cover Female Plugs Part with Three Holes

File Header:

0 ~Electric Switch: Cover Female Plugs Part with Three Holes
0 Name: 4710c.dat
0 Author: Javier Orquera [kuramapika1]
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2025-04-24 [kuramapika1] Added new subfile and changed number

Show contents

1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\4113s01.dat
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\4710s01.dat
4 16 54.6 12.6 20 54.6 21.6 20 25.6 21.6 20 25.6 12.6 20
4 16 -54.6 12.6 20 -34 13 20 -34 17 20 -54.6 21.6 20
3 16 -34 17 20 -34 21 20 -54.6 21.6 20
4 16 -34 17 18 -34 13 18 -54.6 12.6 18 -54.6 21.6 18
3 16 -34 17 18 -54.6 21.6 18 -34 21 18
4 16 54.6 12.6 18 25.6 12.6 18 25.6 21.6 18 54.6 21.6 18
1 16 -30 17 18 4 0 0 0 0 -4 0 1 0 4-4ndis.dat
0 BFC INVERTNEXT
1 16 -30 17 20 4 0 0 0 0 4 0 -2 0 4-4cylo.dat
1 16 -30 17 20 4 0 0 0 0 4 0 -1 0 4-4ndis.dat
1 16 -20 17 18 3.5 0 0 0 0 3.5 0 1 0 4-4ndis.dat
0 BFC INVERTNEXT
1 16 -20 17 20 3.5 0 0 0 0 3.5 0 -2 0 4-4cylo.dat
1 16 -20 17 20 3.5 0 0 0 0 3.5 0 -1 0 4-4ndis.dat
1 16 -10 17 18 4 0 0 0 0 -4 0 1 0 4-4ndis.dat
0 BFC INVERTNEXT
1 16 -10 17 20 4 0 0 0 0 4 0 -2 0 4-4cylo.dat
1 16 -10 17 20 4 0 0 0 0 4 0 -1 0 4-4ndis.dat
4 16 -26 13 20 -14 13 20 -16.5 13.5 20 -20 13.5 20
3 16 -20 13.5 20 -23.5 13.5 20 -26 13 20
4 16 -16.5 13.5 20 -14 13 20 -14 17 20 -16.5 17 20
4 16 -16.5 17 20 -14 17 20 -14 21 20 -16.5 20.5 20
4 16 -26 17 20 -26 13 20 -23.5 13.5 20 -23.5 17 20
4 16 -26 17 20 -23.5 17 20 -23.5 20.5 20 -26 21 20
3 16 -26 21 20 -23.5 20.5 20 -20 20.5 20
4 16 -26 21 20 -20 20.5 20 -16.5 20.5 20 -14 21 20
4 16 -16.5 13.5 18 -14 13 18 -26 13 18 -20 13.5 18
3 16 -23.5 13.5 18 -20 13.5 18 -26 13 18
4 16 -14 17 18 -14 13 18 -16.5 13.5 18 -16.5 17 18
4 16 -14 21 18 -14 17 18 -16.5 17 18 -16.5 20.5 18
4 16 -23.5 13.5 18 -26 13 18 -26 17 18 -23.5 17 18
4 16 -23.5 20.5 18 -23.5 17 18 -26 17 18 -26 21 18
3 16 -23.5 20.5 18 -26 21 18 -20 20.5 18
4 16 -16.5 20.5 18 -20 20.5 18 -26 21 18 -14 21 18
4 16 -30 13 20 -34 13 20 -54.6 12.6 20 -5.6 12.6 20
3 16 -26 13 20 -30 13 20 -5.6 12.6 20
3 16 -14 13 20 -26 13 20 -5.6 12.6 20
3 16 -14 13 20 -5.6 12.6 20 -10 13 20
3 16 -10 13 20 -5.6 12.6 20 -6 13 20
4 16 -6 17 20 -6 13 20 -5.6 12.6 20 -5.6 21.6 20
3 16 -6 17 20 -5.6 21.6 20 -6 21 20
4 16 -54.6 21.6 20 -34 21 20 -30 21 20 -5.6 21.6 20
3 16 -30 21 20 -26 21 20 -5.6 21.6 20
3 16 -5.6 21.6 20 -26 21 20 -14 21 20
3 16 -5.6 21.6 20 -14 21 20 -10 21 20
3 16 -5.6 21.6 20 -10 21 20 -6 21 20
4 16 -54.6 12.6 18 -34 13 18 -30 13 18 -5.6 12.6 18
3 16 -30 13 18 -26 13 18 -5.6 12.6 18
3 16 -26 13 18 -14 13 18 -5.6 12.6 18
3 16 -5.6 12.6 18 -14 13 18 -10 13 18
3 16 -5.6 12.6 18 -10 13 18 -6 13 18
4 16 -5.6 12.6 18 -6 13 18 -6 17 18 -5.6 21.6 18
3 16 -5.6 21.6 18 -6 17 18 -6 21 18
4 16 -30 21 18 -34 21 18 -54.6 21.6 18 -5.6 21.6 18
3 16 -26 21 18 -30 21 18 -5.6 21.6 18
3 16 -26 21 18 -5.6 21.6 18 -14 21 18
3 16 -14 21 18 -5.6 21.6 18 -10 21 18
3 16 -10 21 18 -5.6 21.6 18 -6 21 18

Status:

Needs More Votes (N)

This part has the following automated holds from the Parts Tracker

Has uncertified subfiles

parts/s/4113s01.dat (Needs More Votes)
parts/s/4710s01.dat (Needs More Votes)

Current Votes:

None

Official parents and subparts

Part Events:

Javier Orquera [kuramapika1]

initially submitted the part.

2025-05-14 18:37:48

Created accordingly on the web page posted in the forums.
