Unofficial File parts/s/4488s01.dat
File Header:
0 ~Plate 2 x 2 with 1 Wheel Pin - Common Part
0 Name: s\4488s01.dat
0 Author: Massimo Maso [Sirio]
0 !LDRAW_ORG Unofficial_Subpart
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
Show contents
0 // Primitives
1 16 0 0 0 0 0 -1 0 1 0 1 0 0 stug-2x2.dat
1 16 10 4 0 1 0 0 0 -3 0 0 0 1 stud3.dat
1 16 -10 4 0 1 0 0 0 -1 0 0 0 1 stud3.dat
0 BFC INVERTNEXT
1 16 10 16 0 6 0 0 0 -12 0 0 0 16 box5.dat
0 BFC INVERTNEXT
1 16 -8 8 0 0 0 -8 0 -4 0 16 0 0 box5-1.dat
1 16 0 4 0 0 -20 0 0 0 -4 20 0 0 box2-5.dat
1 16 0 12 0 0 1 0 0 0 4 20 0 0 recte3.dat
1 16 10 16 0 0 0 10 0 1 0 20 0 0 recte3.dat
1 16 20 8 0 0 -1 0 8 0 0 0 0 20 rect2p.dat
0 // Faces
4 16 4 16 -16 16 16 -16 20 16 -20 0 16 -20
4 16 4 16 16 4 16 -16 0 16 -20 0 16 20
4 16 16 16 16 4 16 16 0 16 20 20 16 20
4 16 16 16 -16 16 16 16 20 16 20 20 16 -20
4 16 -16 8 -16 0 8 -16 0 8 -20 -20 8 -20
4 16 -16 8 16 -16 8 -16 -20 8 -20 -20 8 20
4 16 0 8 16 -16 8 16 -20 8 20 0 8 20
4 16 0 8 20 20 0 20 20 16 20 0 16 20
4 16 0 16 -20 20 16 -20 20 0 -20 0 8 -20
4 16 0 8 20 -20 8 20 -20 0 20 20 0 20
4 16 -20 8 -20 0 8 -20 20 0 -20 -20 0 -20
4 16 0 8 -16 0 8 16 0 16 20 0 16 -20
3 16 0 16 -20 0 8 -20 0 8 -16
3 16 0 16 20 0 8 16 0 8 20
0 // Edges
2 24 0 8 20 -20 8 20
2 24 -20 8 -20 0 8 -20
2 24 0 8 -20 0 8 -16
2 24 0 8 16 0 8 20
0 // Base of wheel pin
0 // Primitives
1 16 20 5 0 0 2 0 -5 0 0 0 0 5 1-8cylo.dat
1 16 20 5 0 0 2 0 -5 0 0 0 0 -5 1-8cylo.dat
1 16 20 5 0 0 2 0 5 0 0 0 0 -5 1-8cylo.dat
1 16 20 5 0 0 2 0 5 0 0 0 0 5 1-8cylo.dat
1 16 22 5 0 0 -1 0 -5 0 0 0 0 5 1-8chrd.dat
1 16 22 5 0 0 -1 0 -5 0 0 0 0 -5 1-8chrd.dat
1 16 22 5 0 0 -1 0 5 0 0 0 0 -5 1-8chrd.dat
1 16 22 5 0 0 -1 0 5 0 0 0 0 5 1-8chrd.dat
1 16 21 5 -7.5 1 -1 0 0 0 3 2.5 0 0 rect.dat
1 16 21 5 7.5 -1 -1 0 0 0 3 2.5 0 0 rect.dat
1 16 22 5 -4.445 0 -1 0 0 0 3 .555 0 0 rect2p.dat
1 16 22 5 4.445 0 -1 0 0 0 3 .555 0 0 rect2p.dat
0 // Faces
4 16 20 2 3.89 22 2 3.89 22 2 5 20 2 10
4 16 20 2 3.89 20 1.47 3.53 22 1.4645 3.5355 22 2 3.89
4 16 20 2 -3.89 20 2 -10 22 2 -5 22 2 -3.89
4 16 20 2 -3.89 22 2 -3.89 22 1.4645 -3.5355 20 1.47 -3.53
4 16 20 8 -3.89 22 8 -3.89 22 8 -5 20 8 -10
4 16 20 8 -3.89 20 8.53 -3.53 22 8.5355 -3.5355 22 8 -3.89
4 16 20 8 3.89 20 8 10 22 8 5 22 8 3.89
4 16 20 8 3.89 22 8 3.89 22 8.5355 3.5355 20 8.53 3.53
4 16 22 1.4645 3.5355 22 8.5355 3.5355 22 8 3.89 22 2 3.89
4 16 22 1.4645 3.5355 22 0 0 22 10 0 22 8.5355 3.5355
4 16 22 1.4645 -3.5355 22 8.5355 -3.5355 22 10 0 22 0 0
4 16 22 1.4645 -3.5355 22 2 -3.89 22 8 -3.89 22 8.5355 -3.5355
0 // Lines
2 24 20 2 3.89 20 2 10
2 24 20 2 3.89 20 1.47 3.53
2 24 20 2 3.89 22 2 3.89
2 24 20 2 -3.89 20 2 -10
2 24 20 2 -3.89 20 1.47 -3.53
2 24 20 2 -3.89 22 2 -3.89
2 24 20 8 -3.89 20 8 -10
2 24 20 8 -3.89 20 8.53 -3.53
2 24 20 8 -3.89 22 8 -3.89
2 24 20 8 3.89 20 8 10
2 24 20 8 3.89 20 8.53 3.53
2 24 20 8 3.89 22 8 3.89
2 24 22 2 3.89 22 1.4645 3.5355
2 24 22 2 -3.89 22 1.4645 -3.5355
2 24 22 8 -3.89 22 8.5355 -3.5355
2 24 22 8 3.89 22 8.5355 3.5355
0 // Conditional lines
5 24 22 1.4645 3.5355 20 1.4645 3.5355 22 .3805 1.9135 22 2 3.89
5 24 22 1.4645 -3.5355 20 1.47 -3.53 22 .3805 -1.9135 22 2 -3.89
5 24 22 8.5355 -3.5355 20 8.5355 -3.5355 22 9.6195 -1.9135 22 8 -3.89
5 24 22 8.5355 3.5355 20 8.5355 3.5355 22 9.6195 1.9135 22 8 3.89
Status:
Needs More Votes (N)
This part has the following automated holds from the Parts Tracker
- No path of certified files to a certified or official parent in the parts folder
Current Votes:
None
Official parents and subparts
Part Events:
2025-05-24 21:32:41
Missing edge lines around the wheel pin, in all parts using this subfile.
Inlined wpin2a and wpin2b. Fixed some overlapping due to the use of this primitives.
Many gaps in the inlined base.
Closed gaps.
