File Detail parts/7452.dat

Unofficial File parts/7452.dat

Part Attributes:

External Sites:

File Header:

0 Bracket 1 x 2 - 2 x 4 up
0 Name: 7452.dat
0 Author: Gerald Lasser [GeraldLasser]
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

Show contents

4 16 20 8 10 20 8 -10 16 8 -10 16 8 6
4 16 -20 8 10 -16 8 6 -16 8 -10 -20 8 -10
4 16 20 8 10 16 8 6 -16 8 6 -20 8 10
0 BFC INVERTNEXT
1 16 0 8 -2 16 0 0 0 -4 0 0 0 8 box4-1.dat
1 16 0 4 0 1 0 0 0 -1 0 0 0 1 stud3.dat
1 16 -10 6 -10 1.5 0 0 0 0 2 0 4 0 box4-2p.dat
1 16 0 6 -10 1.5 0 0 0 0 2 0 4 0 box4-2p.dat
1 16 10 6 -10 1.5 0 0 0 0 2 0 4 0 box4-2p.dat
1 16 0 8 0 20 0 0 0 -8 0 0 0 10 box4-1.dat
1 16 0 0 -0 -1 0 -0 0 1 -0 0 -0 -1 stug-1x2.dat
2 24 -16 8 -10 -11.5 8 -10
2 24 -8.5 8 -10 -1.5 8 -10
2 24 1.5 8 -10 8.5 8 -10
2 24 11.5 8 -10 16 8 -10
4 16 -16 4 -10 -11.5 4 -10 -11.5 8 -10 -16 8 -10
4 16 11.5 8 -10 11.5 4 -10 16 4 -10 16 8 -10
4 16 1.5 4 -10 8.5 4 -10 8.5 8 -10 1.5 8 -10
4 16 -8.5 8 -10 -8.5 4 -10 -1.5 4 -10 -1.5 8 -10

0 // Vertical
3 16 -38 8 -14 -38 8 -10 -20 8 -10
3 16 -38 8 -14 -20 8 -10 -16 8 -10
3 16 -38 8 -14 -16 8 -10 -11.5 8 -10
3 16 -38 8 -14 -11.5 8 -10 -8.5 8 -10
3 16 -38 8 -14 -8.5 8 -10 -1.5 8 -10
4 16 -1.5 8 -10 1.5 8 -10 38 8 -14 -38 8 -14
3 16 38 8 -10 38 8 -14 20 8 -10
3 16 20 8 -10 38 8 -14 16 8 -10
3 16 16 8 -10 38 8 -14 11.5 8 -10
3 16 11.5 8 -10 38 8 -14 8.5 8 -10
3 16 8.5 8 -10 38 8 -14 1.5 8 -10
2 24 38 8 -14 -38 8 -14
2 24 -20 8 -10 -38 8 -10
2 24 20 8 -10 38 8 -10

1 16 -38 6 -10 0 0 -2 2 0 0 0 -4 0 1-4cylo.dat
1 16 38 6 -14 0 0 2 2 0 0 0 4 0 1-4cylo.dat
1 16 -38 6 -14 -2 0 0 0 0 2 0 1 0 1-4chrd.dat
1 16 38 6 -14 2 0 0 0 0 2 0 1 0 1-4chrd.dat
1 16 38 6 -10 2 0 0 0 0 2 0 -1 0 1-4chrd.dat
1 16 -38 6 -10 -2 0 0 0 0 2 0 -1 0 1-4chrd.dat
4 16 -20 0 -10 -20 8 -10 -38 8 -10 -40 4 -10
4 16 -20 0 -10 -40 4 -10 -40 -30 -10 -38 -32 -10
4 16 -20 0 -10 -38 -32 -10 38 -32 -10 20 0 -10
4 16 20 0 -10 38 -32 -10 40 -30 -10 40 6 -10
4 16 20 0 -10 40 6 -10 38 8 -10 20 8 -10
4 16 -40 6 -14 -38 8 -14 38 8 -14 40 6 -14
1 16 0 -12 -10 0 0 40 -18 0 0 0 -4 0 box3u8p.dat
1 16 -38 -30 -10 0 0 -2 -2 0 0 0 -4 0 1-4cylo.dat
1 16 38 -30 -14 0 0 2 -2 0 0 0 4 0 1-4cylo.dat
1 16 -38 -30 -14 -2 0 0 0 0 -2 0 1 0 1-4chrd.dat
1 16 38 -30 -14 2 0 0 0 0 -2 0 1 0 1-4chrd.dat
1 16 38 -30 -10 2 0 0 0 0 -2 0 -1 0 1-4chrd.dat
1 16 -38 -30 -10 -2 0 0 0 0 -2 0 -1 0 1-4chrd.dat
4 16 40 -30 -14 38 -32 -14 -38 -32 -14 -40 -30 -14
1 16 0 -32 -12 36 0 0 0 1 0 0 0 2 rect2p.dat

1 16 -20 -12 -14 1 0 0 0 0 -1 0 1 0 stug2-2x2.dat
1 16 20 -12 -14 1 0 0 0 0 -1 0 1 0 stug2-2x2.dat

Status:

Needs More Votes (N)

Current Votes:

None

Official parents and subparts

Part Events:

Gerald Lasser [GeraldLasser]

initially submitted the part.

2025-10-02 12:54:17

Rene Rechthaler [Blechtaler]

posted a vote of Hold.

2025-10-02 14:45:02

-misses the bottom bracket edgelines
-sides have too many edgelines (wrong box?)
-corners R2 or R4?

Gerald Lasser [GeraldLasser]

submitted a new version of the part.

2025-10-02 16:53:29

fixed
I used R4 as this was used in the similar sized brackets

BI is 2.5

Rene Rechthaler [Blechtaler]

made the following comment.

2025-10-02 17:16:43

hm, all "modern" ones have 2...
should this use an additional vertex at the center of the bottom edge to improve the triangles to the stud holder boxes?

Gerald Lasser [GeraldLasser]

submitted a new version of the part.

2025-10-02 18:45:03

R2 looks better
Bottom is still ok

Rene Rechthaler [Blechtaler]

made the following comment.

2025-10-02 19:45:36

you forgot to stretch the top rect2p, its too short now
lower left corner also has a gap at the rear
the rest looks better
