0 Technic Connector Toggle Joint Toothed
0 Name: 4273b.dat
0 Author: James Jessiman
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !KEYWORDS BrickLink 4273

0 !HISTORY 2000-02-08 [sbliss] Changed part name from Technic Connector Locking
0 !HISTORY 2000-05-07 [PTadmin] Official Update 2000-01
0 !HISTORY 2007-07-04 [PTadmin] Header formatted for Contributor Agreement
0 !HISTORY 2008-07-01 [PTadmin] Official Update 2008-01
0 !HISTORY 2008-07-07 [guyvivan] Made BFC compliant, Add missing disc, ring8, optional lines
0 !HISTORY 2008-07-07 [PTadmin] Renamed from 4273
0 !HISTORY 2011-12-29 [PTadmin] Official Update 2011-02
0 !HISTORY 2018-10-08 [MagFors] Adapted to updated bush lock primitives
0 !HISTORY 2018-10-11 [MagFors] Subfiled
0 !HISTORY 2018-12-08 [PTadmin] Official Update 2018-02
0 !HISTORY 2025-11-02 [OrionP] Fix Invalid lines
