0 ~Plate 2 x 2 with Pin and Small Support Ring - Common Geometry
0 Name: s\2476cs01.dat
0 Author: Gerald Lasser [GeraldLasser]
0 !LDRAW_ORG Unofficial_Subpart
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
4 16 20 8 20 16 8 16 -16 8 16 -20 8 20
4 16 -20 8 -20 -16 8 -16 16 8 -16 20 8 -20
4 16 20 8 -20 16 8 -16 16 8 16 20 8 20
4 16 -20 8 20 -16 8 16 -16 8 -16 -20 8 -20
0 BFC INVERTNEXT
1 16 0 8 0 16 0 0 0 -4 0 0 0 16 box5.dat
1 16 0 4 0 11 0 0 0 4 0 0 0 11 4-4cylo.dat
1 16 0 8 0 1 0 0 0 -1 0 0 0 -1 4-4ring9.dat
1 16 0 8 0 1 0 0 0 -1 0 0 0 -1 4-4ring10.dat
0 BFC INVERTNEXT
1 16 0 4 0 9 0 0 0 4 0 0 0 9 4-4cylo.dat
1 16 0 8 0 20 0 0 0 -8 0 0 0 20 box5.dat
1 16 0 0 0 1 0 0 0 1 0 0 0 1 stug2-2x2.dat
- No path of certified files to a certified or official parent in the parts folder
None
history:
0 !HISTORY 2026-01-25 [GeraldLasser] Reduced inner Ring to actual measurement
to
0 !HISTORY 2026-01-25 [GeraldLasser] Corrected support Ring Dimensions
proper wording
https://v4ei.com/brickref/variants/2476-2x2-plate-with-underside-pin/index.php
description:
~Plate 2 x 2 with Pin - Common Geometry
to
~Plate 2 x 2 with Pin and Small Support Ring - Common Geometry
description:
~Plate 2 x 2 with Pin and Small Support Ring - Common Geometry
to
~Plate 2 x 2 with Pin and Small Support Ring - Common Geometry
This part is copyright ©
Gerald Lasser
Licensed under
CC BY 4.0
corrected the supprt ring geometry along the way
