File Detail parts/s/7798s01.dat

Unofficial File parts/s/7798s01.dat

~Tile 6 x 6 with Rounded Underside Corners without Top Face

File Header:

0 ~Tile  6 x  6 with Rounded Underside Corners without Top Face
0 Name: s\7798s01.dat
0 Author: Peter Grass [Evilspyre]
0 !LDRAW_ORG Unofficial_Subpart
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

Show contents

0 BFC INVERTNEXT
1 16 0 8 0 56 0 0 0 -4 0 0 0 56 box5.dat
1 16 0 7 0 60 0 0 0 -7 0 0 0 60 box4.dat
3 16 -59.098 7 -59.094 -60 7 -60 -59.5 7 -58.066
4 16 -59.5 7 -58.066 -60 7 -60 -60 7 60 -59.5 7 58.066
3 16 -60 7 60 -59.098 7 59.094 -59.5 7 58.066
3 16 -58.069 7 -59.5 -60 7 -60 -59.098 7 -59.094
4 16 60 7 -60 -60 7 -60 -58.069 7 -59.5 58.069 7 -59.5
3 16 60 7 -60 58.069 7 -59.5 59.098 7 -59.094
4 16 -59.5 7 58.066 -59.2 8 57.794 -59.2 8 -57.794 -59.5 7 -58.066
3 16 -58.833 8 -58.833 -59.5 7 -58.066 -59.2 8 -57.794
3 16 -58.833 8 -58.833 -59.098 7 -59.094 -59.5 7 -58.066
3 16 -58.833 8 58.833 -59.2 8 57.794 -59.5 7 58.066
3 16 -58.833 8 58.833 -59.5 7 58.066 -59.098 7 59.094
4 16 58.069 7 -59.5 -58.069 7 -59.5 -57.794 8 -59.2 57.794 8 -59.2
3 16 -58.833 8 -58.833 -57.794 8 -59.2 -58.069 7 -59.5
3 16 -58.833 8 -58.833 -58.069 7 -59.5 -59.098 7 -59.094
3 16 58.069 7 -59.5 57.794 8 -59.2 58.833 8 -58.833
3 16 58.069 7 -59.5 58.833 8 -58.833 59.098 7 -59.094
3 16 58.833 8 -58.833 59.5 7 -58.066 59.098 7 -59.094
3 16 58.833 8 -58.833 59.2 8 -57.794 59.5 7 -58.066
3 16 58.833 8 58.833 59.5 7 58.066 59.2 8 57.794
3 16 58.833 8 58.833 59.098 7 59.094 59.5 7 58.066
3 16 60 7 -60 59.098 7 -59.094 59.5 7 -58.066
4 16 59.5 7 -58.066 59.5 7 58.066 60 7 60 60 7 -60
3 16 59.098 7 59.094 60 7 60 59.5 7 58.066
4 16 58.069 7 59.5 -58.069 7 59.5 -60 7 60 60 7 60
3 16 -60 7 60 -58.069 7 59.5 -59.098 7 59.094
3 16 58.069 7 59.5 60 7 60 59.098 7 59.094
3 16 -58.069 7 59.5 -58.833 8 58.833 -59.098 7 59.094
3 16 -58.069 7 59.5 -57.794 8 59.2 -58.833 8 58.833
4 16 57.794 8 59.2 -57.794 8 59.2 -58.069 7 59.5 58.069 7 59.5
3 16 58.833 8 58.833 57.794 8 59.2 58.069 7 59.5
3 16 58.833 8 58.833 58.069 7 59.5 59.098 7 59.094
4 16 -59.2 8 57.794 -56 8 56 -56 8 -56 -59.2 8 -57.794
4 16 -58.833 8 -58.833 -59.2 8 -57.794 -56 8 -56 -57.794 8 -59.2
4 16 57.794 8 -59.2 56.002 8 -56 59.2 8 -57.794 58.833 8 -58.833
4 16 -58.833 8 58.833 -57.794 8 59.2 -56 8 56 -59.2 8 57.794
4 16 59.2 8 57.794 59.2 8 -57.794 56.002 8 -56 56 8 56
4 16 57.794 8 59.2 56 8 56 -56 8 56 -57.794 8 59.2
4 16 57.794 8 59.2 58.833 8 58.833 59.2 8 57.794 56 8 56
5 24 -58.069 7 59.5 -58.833 8 58.833 -57.794 8 59.2 -59.098 7 59.094
5 24 58.833 8 58.833 59.098 7 59.094 58.069 7 59.5 59.5 7 58.066
5 24 58.833 8 58.833 59.5 7 58.066 59.2 8 57.794 59.098 7 59.094
5 24 58.069 7 -59.5 57.794 8 -59.2 58.833 8 -58.833 -58.069 7 -59.5
5 24 59.5 7 58.066 59.2 8 57.794 59.5 7 -58.066 58.833 8 58.833
2 24 59.2 8 57.794 58.833 8 58.833
2 24 59.098 7 59.094 59.5 7 58.066
2 24 57.794 8 -59.2 58.833 8 -58.833
2 24 -59.2 8 57.794 -59.2 8 -57.794
5 24 -58.833 8 58.833 -59.098 7 59.094 -59.5 7 58.066 -58.069 7 59.5
2 24 59.098 7 -59.094 59.5 7 -58.066
2 24 58.833 8 -58.833 59.2 8 -57.794
2 24 58.069 7 59.5 -58.069 7 59.5
2 24 57.794 8 59.2 -57.794 8 59.2
2 24 58.069 7 -59.5 59.098 7 -59.094
5 24 -58.069 7 59.5 -57.794 8 59.2 -58.833 8 58.833 58.069 7 59.5
2 24 -57.794 8 59.2 -58.833 8 58.833
2 24 -58.833 8 -58.833 -57.794 8 -59.2
5 24 -59.5 7 -58.066 -59.2 8 -57.794 -59.5 7 58.066 -58.833 8 -58.833
5 24 58.833 8 -58.833 59.098 7 -59.094 59.5 7 -58.066 58.069 7 -59.5
2 24 -59.098 7 59.094 -59.5 7 58.066
2 24 -59.2 8 -57.794 -58.833 8 -58.833
2 24 -58.069 7 -59.5 58.069 7 -59.5
2 24 -58.833 8 58.833 -59.2 8 57.794
2 24 -59.5 7 -58.066 -59.098 7 -59.094
5 24 -59.2 8 57.794 -59.5 7 58.066 -58.833 8 58.833 -59.2 8 -57.794
2 24 59.5 7 58.066 59.5 7 -58.066
5 24 -59.5 7 58.066 -58.833 8 58.833 -59.098 7 59.094 -59.2 8 57.794
5 24 58.833 8 -58.833 58.069 7 -59.5 57.794 8 -59.2 59.098 7 -59.094
5 24 -58.069 7 -59.5 -58.833 8 -58.833 -59.098 7 -59.094 -57.794 8 -59.2
2 24 -59.5 7 58.066 -59.5 7 -58.066
5 24 58.833 8 -58.833 59.5 7 -58.066 59.2 8 -57.794 59.098 7 -59.094
2 24 -59.098 7 -59.094 -58.069 7 -59.5
2 24 59.2 8 -57.794 59.2 8 57.794
2 24 -58.069 7 59.5 -59.098 7 59.094
2 24 59.098 7 59.094 58.069 7 59.5
5 24 -58.833 8 -58.833 -59.098 7 -59.094 -58.069 7 -59.5 -59.5 7 -58.066
2 24 -57.794 8 -59.2 57.794 8 -59.2
2 24 58.833 8 58.833 57.794 8 59.2
5 24 -57.794 8 -59.2 -58.069 7 -59.5 57.794 8 -59.2 -58.833 8 -58.833
5 24 57.794 8 59.2 58.069 7 59.5 -57.794 8 59.2 58.833 8 58.833
5 24 -58.833 8 -58.833 -59.5 7 -58.066 -59.098 7 -59.094 -59.2 8 -57.794
5 24 59.2 8 -57.794 59.5 7 -58.066 58.833 8 -58.833 59.2 8 57.794
5 24 58.069 7 59.5 58.833 8 58.833 57.794 8 59.2 59.098 7 59.094
4 16 59.5 7 58.066 59.5 7 -58.066 59.2 8 -57.794 59.2 8 57.794
4 16 -57.794 8 -59.2 -56 8 -56 56 8 -56 57.794 8 -59.2

Status:

Needs 2 More Votes (N)

This part has the following automated holds from the Parts Tracker

No path of certified files to a certified or official parent in the parts folder

Current Votes:

None

Official parents and subparts

Part Events:

Peter Grass [Evilspyre]

initially submitted the part.

2026-03-06 01:03:36

Rene Rechthaler [Blechtaler]

made the following comment.

2026-03-07 22:48:23

why the slightly slanted groove? would it work with vertical 1x1 LDU groove (rect2p) and p8 1-4cylo corners?
