Unofficial File parts/3398p01.dat
Warning: Model breaking changes to unofficial parts may occur anytime prior to release
0 Minifig Hips SMART Play Tag with SW Luke Skywalker Tunic and Belt Pattern
0 Name: 3398p01.dat
0 Author: Philippe Hurbain [Philo]
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !CATEGORY Minifig
0 !KEYWORDS Bricklink bb1407pb002c01, Set 75420, Set 75426Show file code:
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\3398s01.dat
1 16 -2 12 0 0 4 0 0 0 -8.75 -8.75 0 0 1-8cyli.dat
5 24 2 20.084 -3.3485 -2 20.084 -3.3485 2 21.4709 0 2 18.1871 -6.1871
5 24 2 15.3486 -8.0841 -2 15.3486 -8.0841 2 18.1871 -6.1871 2 12 -8.75
5 24 2 18.1871 -6.1871 -2 18.1871 -6.1871 2 20.084 -3.3485 2 15.3486 -8.0841
5 24 2 12 -8.75 -2 12 -8.75 2 15.3486 -8.0841 2 8.6514 -8.0841
5 24 2 5.8129 -6.1871 -2 5.8129 -6.1871 2 8.6514 -8.0841 2 3.2496 -3.6245
4 0 -14.435 5.1095 -10 -14.5254 .8777 -10 -15.1727 .856 -10 -14.9305 5.1159 -10
4 0 -2 15.3486 -8.0841 -2 15.4873 -7.9911 2 15.4873 -7.9911 2 15.3486 -8.0841
4 0 2 15.0043 -8.1524 -2 15.0043 -8.1524 -2 15.3486 -8.0841 2 15.3486 -8.0841
4 16 -12.2957 5.1083 -10 -12.7355 5.0838 -10 -14.435 5.1095 -10 -18 6 -10
4 16 2 20.084 -3.3485 2 18.1871 -6.1871 -2 18.1871 -6.1871 -2 20.084 -3.3485
4 16 2 15.0043 -8.1524 2 12 -8.75 -2 12 -8.75 -2 15.0043 -8.1524
4 16 -2 18.1871 -6.1871 2 18.1871 -6.1871 2 18.038 -6.2871 -2 18.0388 -6.2866
4 16 14.6059 .8706 -10 13.0618 2.666 -10 13.1688 5.1053 -10 15.2015 3.4304 -10
3 16 14.9604 .8619 -10 15.1059 1.2948 -10 18 0 -10
4 16 12.7748 5.0932 -10 -12.2957 5.1083 -10 -18 6 -10 18 6 -10
4 16 -14.5254 .8777 -10 -14.435 5.1095 -10 -12.7355 5.0838 -10 -12.9211 .8702 -10
4 16 -18 0 -10 -18 6 -10 -14.9305 5.1159 -10 -15.1727 .856 -10
3 16 -14.435 5.1095 -10 -14.9305 5.1159 -10 -18 6 -10
4 16 18 0 -10 -18 0 -10 -12.4016 .9013 -10 12.3383 .8555 -10
4 16 -15.1727 .856 -10 -14.5254 .8777 -10 -12.9211 .8702 -10 -18 0 -10
3 16 -18 0 -10 -12.9211 .8702 -10 -12.4016 .9013 -10
4 16 -12.4016 .9013 -10 -12.2957 5.1083 -10 12.7748 5.0932 -10 12.3383 .8555 -10
4 16 15.2015 3.4304 -10 18 6 -10 18 0 -10 15.2804 2.6038 -10
3 16 14.6059 .8706 -10 12.8029 .8635 -10 13.0618 2.666 -10
3 16 13.1688 5.1053 -10 12.7748 5.0932 -10 18 6 -10
3 16 13.1688 5.1053 -10 18 6 -10 15.2015 3.4304 -10
3 16 12.3383 .8555 -10 12.8029 .8635 -10 18 0 -10
4 16 12.8029 .8635 -10 14.6059 .8706 -10 14.9604 .8619 -10 18 0 -10
3 16 15.1059 1.2948 -10 15.2804 2.6038 -10 18 0 -10
4 19 2 16.0505 -7.6149 -2 16.0505 -7.6149 -2 18.0388 -6.2866 2 18.038 -6.2871
4 28 2 15.4873 -7.9911 -2 15.4873 -7.9911 -2 16.0505 -7.6149 2 16.0505 -7.6149
3 71 12.7748 5.0932 -10 13.1688 5.1053 -10 13.0618 2.666 -10
4 71 15.1059 1.2948 -10 14.6059 .8706 -10 15.2015 3.4304 -10 15.2804 2.6038 -10
4 71 12.7748 5.0932 -10 13.0618 2.666 -10 12.8029 .8635 -10 12.3383 .8555 -10
3 71 15.1059 1.2948 -10 14.9604 .8619 -10 14.6059 .8706 -10
4 71 -12.2957 5.1083 -10 -12.4016 .9013 -10 -12.9211 .8702 -10 -12.7355 5.0838 -10Status
Needs 2 More Votes (N)
Current Votes:
No recorded votesThis part has the following warnings
- Category: Minifig is retired, use use suitable active Minifig category
This part has the following automated holds from the Parts Tracker
-
Has Uncertified Subfiles
Part Dependencies
Official parents and subparts
Part Events
Philippe Hurbain [Philo]
initially submitted the part.
2026-03-13 09:09:58
Rene Rechthaler [Blechtaler]
made the following comment.
2026-03-13 16:24:51
could also need some triangles->quads rectifying
Philippe Hurbain [Philo]
submitted a new version of the part (all votes reset).
2026-03-13 17:45:04
Oh yes, rectified
