Unofficial File parts/8193.dat
Part Attributes:
File Header:
0 Tail 1.5 x 1 x 1
0 Name: 8193.dat
0 Author: Rene Rechthaler [Blechtaler]
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !CATEGORY Wing
0 !KEYWORDS Brickowl 184474
0 !HISTORY 2026-06-01 {LEGO Instructions App} Original part shape
0 !HISTORY 2026-06-03 [Blechtaler] File preparation for LDraw Parts Tracker
Show contents
0 // top
1 16 0 0 0 0 0 1 0 1 0 -1 0 0 stud2.dat
1 16 0 4 0 0 0 10 0 -4 0 8 0 0 box3u8p.dat
1 16 8 0 8 2 0 0 0 4 0 0 0 2 1-4cylo.dat
1 16 8 0 -8 2 0 0 0 4 0 0 0 -2 1-4cylo.dat
1 16 -8 0 8 -2 0 0 0 4 0 0 0 2 1-4cylo.dat
1 16 -8 0 -8 -2 0 0 0 4 0 0 0 -2 1-4cylo.dat
1 16 8 0 8 2 0 0 0 1 0 0 0 2 1-4chrd.dat
1 16 8 0 -8 2 0 0 0 1 0 0 0 -2 1-4chrd.dat
1 16 -8 0 8 -2 0 0 0 1 0 0 0 2 1-4chrd.dat
1 16 -8 0 -8 -2 0 0 0 1 0 0 0 -2 1-4chrd.dat
1 16 8 4 8 2 0 0 0 -1 0 0 0 2 1-4chrd.dat
1 16 8 4 -8 2 0 0 0 -1 0 0 0 -2 1-4chrd.dat
1 16 -8 4 8 -2 0 0 0 -1 0 0 0 2 1-4chrd.dat
1 16 -8 4 -8 -2 0 0 0 -1 0 0 0 -2 1-4chrd.dat
1 16 5.5 4 0 2.5 0 0 0 -1 0 0 0 10 rect2p.dat
1 16 -5.5 4 0 2.5 0 0 0 -1 0 0 0 10 rect2p.dat
2 24 8 0 10 -8 0 10
2 24 3 4 10 -3 4 10
2 24 8 0 -10 -8 0 -10
2 24 3 4 -10 -3 4 -10
4 16 10 0 8 8 0 10 -8 0 10 -10 0 8
4 16 8 0 10 3 4 10 -3 4 10 -8 0 10
3 16 8 0 10 8 4 10 3 4 10
3 16 -3 4 10 -8 4 10 -8 0 10
4 16 8 4 10 10 4 8 10 4 -8 8 4 -10
4 16 -10 4 8 -8 4 10 -8 4 -10 -10 4 -8
3 16 3 4 -10 8 4 -10 8 0 -10
3 16 -8 4 -10 -3 4 -10 -8 0 -10
4 16 -3 4 -10 3 4 -10 8 0 -10 -8 0 -10
4 16 -10 0 -8 -8 0 -10 8 0 -10 10 0 -8
0 // bottom
0 BFC INVERTNEXT
1 16 0 24 -10 6 0 0 0 -4 0 0 0 6 box5.dat
1 16 0 24 -10 10 0 0 0 1 0 0 0 10 recte4.dat
4 16 6 24 -16 6 24 -4 10 24 0 10 24 -20
4 16 6 24 -4 -6 24 -4 -10 24 0 10 24 0
4 16 -6 24 -4 -6 24 -16 -10 24 -20 -10 24 0
4 16 -6 24 -16 6 24 -16 10 24 -20 -10 24 -20
1 16 6.5 20 -10 0 0 3.5 0 -4 0 10 0 0 box2-7.dat
1 16 -6.5 20 -10 0 0 -3.5 0 -4 0 10 0 0 box2-7.dat
2 24 3 16 0 -3 16 0
2 24 3 16 -20 -3 16 -20
3 16 10 16 0 10 24 0 3 16 0
4 16 -3 16 0 3 16 0 10 24 0 -10 24 0
3 16 -10 16 0 -3 16 0 -10 24 0
3 16 10 24 -20 10 16 -20 3 16 -20
4 16 -3 16 -20 -10 24 -20 10 24 -20 3 16 -20
3 16 -10 24 -20 -3 16 -20 -10 16 -20
0 // fin
1 16 0 5.2 -1 2 0 0 0 9.6 0 0 -8 10 box4o8a.dat
0 BFC INVERTNEXT
1 16 3 5.2 -11 -1 0 0 0 0 -1.2 0 20 1 1-4cylo.dat
0 BFC INVERTNEXT
1 16 -3 5.2 -11 1 0 0 0 0 -1.2 0 20 1 1-4cylo.dat
0 BFC INVERTNEXT
1 16 3 14.8 -19 -1 0 0 0 0 1.2 0 20 -1 1-4cylo.dat
0 BFC INVERTNEXT
1 16 -3 14.8 -19 1 0 0 0 0 1.2 0 20 -1 1-4cylo.dat
1 16 3 5.2 9 -1 0 0 0 0 -1.2 0 -1 1 1-4ndis.dat
1 16 -3 5.2 9 1 0 0 0 0 -1.2 0 -1 1 1-4ndis.dat
1 16 3 14.8 1 -1 0 0 0 0 1.2 0 -1 -1 1-4ndis.dat
1 16 -3 14.8 1 1 0 0 0 0 1.2 0 -1 -1 1-4ndis.dat
1 16 3 5.2 -11 -1 0 0 0 0 -1.2 0 1 1 1-4ndis.dat
1 16 -3 5.2 -11 1 0 0 0 0 -1.2 0 1 1 1-4ndis.dat
1 16 3 14.8 -19 -1 0 0 0 0 1.2 0 1 -1 1-4ndis.dat
1 16 -3 14.8 -19 1 0 0 0 0 1.2 0 1 -1 1-4ndis.dat
4 16 2 5.2 9 -2 5.2 9 -2 4 10 2 4 10
4 16 2 16 0 -2 16 0 -2 14.8 1 2 14.8 1
4 16 2 5.2 -11 2 4 -10 -2 4 -10 -2 5.2 -11
4 16 2 16 -20 2 14.8 -19 -2 14.8 -19 -2 16 -20
Status:
Needs 2 More Votes (N)
Current Votes:
None
Official parents and subparts
Part Events:
so far only in the orange FnF SupraMk4 (but its universal enough to be used somewhere else)
2026-06-03 10:51:01
Isn't this technically a "tail", like these parts?
https://library.ldraw.org/parts/2082
https://library.ldraw.org/parts/6128
https://library.ldraw.org/parts/2082
https://library.ldraw.org/parts/6128
2026-06-03 10:58:06
Is there a reason the top stud is rotated around the y-axis?
It probably makes no difference, but still looks a bit funny in the code.
It probably makes no difference, but still looks a bit funny in the code.
2026-06-03 11:05:50
T-junk:
2 3 2 4 10 -2 4 10
2 3 -2 4 -10 2 4 -10
2 3 -2 16 -20 2 16 -20
2 3 2 16 0 -2 16 0
2 3 2 4 10 -2 4 10
2 3 -2 4 -10 2 4 -10
2 3 -2 16 -20 2 16 -20
2 3 2 16 0 -2 16 0
2026-06-03 16:40:22
also available in LBG in the same set, but I would also go for "Tail"
Header Edits
description:
Wing 1.5 x 1 x 1
to
Tail 1.5 x 1 x 1
dimensions/origin correct? as this part has a .5 offset...
2026-06-03 19:25:14
I'd say yes, but the Description of 2340 might be wrong... Shouldn't it be 1x5x3 not 1x4x3? 3479 seems ok.
2026-06-03 20:26:17
Support?
Think the order should be Z x X
Think the order should be Z x X
2026-06-03 21:15:05
Sorry, I meant it should be X x Z.
Creative Commons Attribution License information
This part is copyright ©
Rene Rechthaler
Licensed under
CC BY 4.0
