File Detail parts/32074.dat

Download Download zip file View patterns/composites/shortcuts

Official File parts/32074.dat

Part Attributes:

~Technic Competition Cannon with Round Bottom Body

File Header:

0 ~Technic Competition Cannon with Round Bottom Body
0 Name: 32074.dat
0 Author: Santeri Piippo [arezey]
0 !LDRAW_ORG Part UPDATE 2024-08
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2012-08-09 [PTadmin] Official Update 2012-02
0 !HISTORY 2018-02-03 [arezey] Adjusted connection with 32075
0 !HISTORY 2024-03-23 [OrionP] Updated ring primitives
0 !HISTORY 2024-09-13 [GeraldLasser] Complete Overhaul, added clips for lid
0 !HISTORY 2024-09-30 [OrionP] Official Update 2024-08
