Official File parts/32087.dat
Part Attributes:
File Header:
0 Train Track 9V Crossing
0 Name: 32087.dat
0 Author: Ludo Soete [ludo]
0 !LDRAW_ORG Part UPDATE 2020-03
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !KEYWORDS BrickLink 32087c01
0 !HISTORY 2002-11-30 [PTadmin] Official Update 2002-05
0 !HISTORY 2007-06-25 [PTadmin] Header formatted for Contributor Agreement
0 !HISTORY 2008-07-01 [PTadmin] Official Update 2008-01
0 !HISTORY 2008-07-07 [ludo] Moved studs from subparts to have stud-logos aligned correctly (2002-12-23)
0 !HISTORY 2010-07-05 [PTadmin] Official Update 2010-02
0 !HISTORY 2013-04-23 [MagFors] Modified with WINDZ for BFC compliance
0 !HISTORY 2013-04-23 [MagFors] Changed colour 383 to 494 (real metal)
0 !HISTORY 2013-04-26 [MagFors] Moved repeated areas to subfile, closed gaps
0 !HISTORY 2013-05-18 [MMR1988] Used the modified 32087s01.dat
0 !HISTORY 2020-12-29 [PTadmin] Official Update 2020-03
