File Detail parts/32474.dat

Download Download zip file View patterns/composites/shortcuts

Official File parts/32474.dat

Part Attributes:

External Sites:

View on Rebrickable View on BrickLink View on Brickset View on BrickOwl

File Header:

0 Technic Ball Joint with Axlehole Blind
0 Name: 32474.dat
0 Author: Magnus Forsberg [MagFors]
0 !LDRAW_ORG Part UPDATE 2024-04
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !KEYWORDS bionicle, Throwbot

0 !HISTORY 2004-04-22 [PTadmin] Official Update 2004-02
0 !HISTORY 2007-05-04 [PTadmin] Header formatted for Contributor Agreement
0 !HISTORY 2008-07-01 [PTadmin] Official Update 2008-01
0 !HISTORY 2008-07-07 [PTadmin] Renamed from 203 (2006-04-13)
0 !HISTORY 2008-10-26 [mikeheide] BFC'ed
0 !HISTORY 2008-10-31 [mikeheide] reduced 4-4sphe.dat to 12.75 to close visible gap
0 !HISTORY 2011-07-25 [PTadmin] Official Update 2011-01
0 !HISTORY 2013-06-30 [cwdee] Qualified description to distinguish from 53585
0 !HISTORY 2013-07-21 [PTadmin] Official Update 2013-01
0 !HISTORY 2014-05-24 [Philo] Subparted top for pattern
0 !HISTORY 2014-06-21 [PTadmin] Official Update 2014-01
0 !HISTORY 2021-08-02 [Berth] Subparted bottom for pattern
0 !HISTORY 2022-09-17 [MagFors] Reshaped for diameter 12.81
0 !HISTORY 2024-05-01 [MagFors] Complete rework due to bad size, original by samrotule
0 !HISTORY 2024-05-28 [OrionP] Official Update 2024-04

Show contents

1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\32474s01.dat
0 // patternable areas
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\32474s02.dat
1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\32474s02.dat
1 16 0 0 0 1 0 0 0 1 0 0 0 -1 s\32474s02.dat
1 16 0 0 0 -1 0 0 0 1 0 0 0 -1 s\32474s02.dat
1 16 0 0 0 12.81 0 0 0 -12.81 0 0 0 -12.81 4-8sphe.dat
