File Detail parts/342c01.dat

Download Download zip file View patterns/composites/shortcuts

Official File parts/342c01.dat

Part Attributes: Base Part: 342.dat

External Sites:

View on Rebrickable View on BrickLink View on BrickOwl

Technic Flex-System Cable 96LDu Long (open file for usage guide)

File Header:

0 Technic Flex-System Cable 96LDu Long (open file for usage guide)
0 Name: 342c01.dat
0 Author: Ross Crawford [rosco]
0 !LDRAW_ORG Shortcut UPDATE 2004-01
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 !HELP A Technic Flex-System is often seen curved in a model. In those cases,
0 !HELP some part of the ends are normally fixed inside another element, while
0 !HELP the rest is bent. The part "342.DAT" is meant to model the straight
0 !HELP parts of the ends. To achieve this, place one at each end point. They
0 !HELP should not be scaled. The part "343.DAT" is meant to model the rest.
0 !HELP If it is curved, you would typically scale the "343.DAT" to a have a
0 !HELP short length, eg. 4LDU, and use many of them along the path of the
0 !HELP curve. In the example below, the end points are 20LDU length, while the
0 !HELP centre part of the hose is scaled to have 56LDU length, thus filling out
0 !HELP the rest of the segment.

0 BFC CERTIFY CW

0 !KEYWORDS BrickLink bb0008c04L, Rebrickable flex08c04

0 !HISTORY 2004-03-02 [PTadmin] Official Update 2004-01
0 !HISTORY 2007-06-25 [PTadmin] Header formatted for Contributor Agreement
0 !HISTORY 2008-07-01 [PTadmin] Official Update 2008-01

Show contents

1 16 0 0 0 0 -1 0 1 0 0 0 0 1 342.dat
1 16 76 0 0 0 -56 0 1 0 0 0 0 1 343.dat
1 16 96 0 0 0 1 0 1 0 0 0 0 -1 342.dat
0
