0 Tipper End Sloped
0 Name: 3436.dat
0 Author: James Jessiman
0 !LDRAW_ORG Part UPDATE 2010-03
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2007-06-25 [PTadmin] Header formatted for Contributor Agreement
0 !HISTORY 2008-07-01 [PTadmin] Official Update 2008-01
0 !HISTORY 2010-10-17 [tchang] Add BFC
0 !HISTORY 2010-12-31 [PTadmin] Official Update 2010-03
Show contents
0 BFC INVERTNEXT
1 16 0 69.28 0 16 0 0 0 -4 0 0 0 6 box5.dat
1 16 0 65.28 0 1 0 0 0 -1 0 0 0 1 stud3.dat
0 //
4 16 20 69.28 10 16 69.28 6 -16 69.28 6 -20 69.28 10
4 16 -20 69.28 10 -16 69.28 6 -16 69.28 -6 -20 69.28 -10
4 16 -20 69.28 -10 -16 69.28 -6 16 69.28 -6 20 69.28 -10
4 16 20 69.28 -10 16 69.28 -6 16 69.28 6 20 69.28 10
2 24 20 69.28 10 -20 69.28 10
2 24 -20 69.28 10 -20 69.28 -10
2 24 -20 69.28 -10 20 69.28 -10
2 24 20 69.28 -10 20 69.28 10
0 //
2 24 20 69.28 10 60 0 10
2 24 -20 69.28 10 -60 0 10
2 24 20 69.28 -10 40 34.64 -50
2 24 -20 69.28 -10 -40 34.64 -50
4 16 60 0 -10 20 69.28 -10 20 69.28 10 60 0 10
4 16 -60 0 10 -20 69.28 10 -20 69.28 -10 -60 0 -10
3 16 60 0 -10 40 34.64 -50 20 69.28 -10
3 16 -20 69.28 -10 -40 34.64 -50 -60 0 -10
4 16 -40 34.64 -50 -20 69.28 -10 20 69.28 -10 40 34.64 -50
0 //
2 24 60 0 10 55.38 0 10
2 24 55.38 0 10 55.38 0 -10
2 24 55.38 0 -10 36.91 31.99 -46.95
2 24 36.91 31.99 -46.95 -36.91 31.99 -46.95
2 24 -36.91 31.99 -46.95 -55.38 0 -10
2 24 -55.38 0 -10 -55.38 0 10
2 24 -55.38 0 10 -60 0 10
2 24 -60 0 10 -60 0 -10
2 24 -60 0 -10 -40 34.64 -50
2 24 -40 34.64 -50 40 34.64 -50
2 24 40 34.64 -50 60 0 -10
2 24 60 0 -10 60 0 10
4 16 60 0 10 55.38 0 10 55.38 0 -10 60 0 -10
4 16 -60 0 -10 -55.38 0 -10 -55.38 0 10 -60 0 10
4 16 60 0 -10 55.38 0 -10 36.91 31.99 -46.95 40 34.64 -50
4 16 -40 34.64 -50 -36.91 31.99 -46.95 -55.38 0 -10 -60 0 -10
4 16 40 34.64 -50 36.91 31.99 -46.95 -36.91 31.99 -46.95 -40 34.64 -50
0 //
2 24 20 61.28 10 55.38 0 10
2 24 -20 61.28 10 -55.38 0 10
2 24 20 61.28 -13.13 36.91 31.99 -46.95
2 24 -20 61.28 -13.13 -36.91 31.99 -46.95
2 24 60 0 -10 55.38 0 -10
2 24 -60 0 -10 -55.38 0 -10
2 24 20 61.28 10 -20 61.28 10
2 24 -20 61.28 10 -20 61.28 -13.13
2 24 -20 61.28 -13.13 20 61.28 -13.13
2 24 20 61.28 -13.13 20 61.28 10
4 16 -20 61.28 10 -20 61.28 -13.13 20 61.28 -13.13 20 61.28 10
4 16 55.38 0 10 20 61.28 10 20 61.28 -13.13 55.38 0 -10
4 16 -55.38 0 -10 -20 61.28 -13.13 -20 61.28 10 -55.38 0 10
3 16 20 61.28 -13.13 36.91 31.99 -46.95 55.38 0 -10
3 16 -55.38 0 -10 -36.91 31.99 -46.95 -20 61.28 -13.13
4 16 36.91 31.99 -46.95 20 61.28 -13.13 -20 61.28 -13.13 -36.91 31.99 -46.95
0 //
4 16 -20 69.28 10 -20 61.28 10 20 61.28 10 20 69.28 10
4 16 20 69.28 10 20 61.28 10 55.38 0 10 60 0 10
4 16 -60 0 10 -55.38 0 10 -20 61.28 10 -20 69.28 10
0 //
1 16 55 8.66 0 -0.5 -0.87 0 0.87 -0.5 0 0 0 1 stud2.dat
1 16 -55 8.66 0 0.5 0.87 0 0.87 -0.5 0 0 0 -1 stud2.dat
1 16 45 25.98 0 -0.5 -0.87 0 0.87 -0.5 0 0 0 1 stud2.dat
1 16 -45 25.98 0 0.5 0.87 0 0.87 -0.5 0 0 0 -1 stud2.dat
1 16 35 43.3 0 -0.5 -0.87 0 0.87 -0.5 0 0 0 1 stud2.dat
1 16 -35 43.3 0 0.5 0.87 0 0.87 -0.5 0 0 0 -1 stud2.dat
1 16 25 60.62 0 -0.5 -0.87 0 0.87 -0.5 0 0 0 1 stud2.dat
1 16 -25 60.62 0 0.5 0.87 0 0.87 -0.5 0 0 0 -1 stud2.dat
0 //
