Official File parts/3815phb.dat
Part Attributes:
Base Part: 3815.dat
File Header:
0 ~Minifig Hips with Purple Greatcoat Pattern (Obsolete)
0 Name: 3815phb.dat
0 Author: Andy Westrate [westrate]
0 !LDRAW_ORG Part UPDATE 2025-09
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !CATEGORY Obsolete
0 !KEYWORDS Harry Potter, Hogwarts, Severus Snape, Slytherin
0 !CMDLINE -c0
0 !HISTORY 2004-04-22 [PTadmin] Official Update 2004-02
0 !HISTORY 2007-07-27 [PTadmin] Header formatted for Contributor Agreement
0 !HISTORY 2008-07-01 [PTadmin] Official Update 2008-01
0 !HISTORY 2009-01-28 [Philo] Moved crotch to main part. Inlined purple subpart
0 !HISTORY 2009-08-24 [PTadmin] Renamed from 970phb
0 !HISTORY 2011-05-10 [Philo] Changed purple part to color 22
0 !HISTORY 2011-07-25 [PTadmin] Official Update 2011-01
0 !HISTORY 2020-05-30 [cwdee] Obsoleted due to bad geometry
0 !HISTORY 2022-01-14 [PTadmin] Official Update 2022-01
0 !HISTORY 2025-09-27 [OrionP] Changed winding to CCW
0 !HISTORY 2025-09-29 [OrionP] Official Update 2025-09
Show contents
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\3815s01.dat
1 16 -2 12 0 0 4 0 -6.364 0 6.364 -6.364 0 -6.364 5-16cyli.dat
3 22 -1 5 -10 1 5 -10 0 3 -10
4 22 14 1 -10 2 5 -10 15.5 5 -10 15 1.5 -10
3 22 0 1 -10 2 5 -10 14 1 -10
4 22 0 1 -10 -14.5 1 -10 -15 5 -10 -2 5 -10
4 8 1 5 -10 2 5 -10 0 1 -10 0 3 -10
4 8 -2 5 -10 -1 5 -10 0 3 -10 0 1 -10
4 8 -15 5 -10 -16 5.75 -10 16.5 5.75 -10 15.5 5 -10
4 8 -16 5.75 -10 -15 5 -10 -14.5 1 -10 -15.25 0.25 -10
4 8 -14.5 1 -10 14 1 -10 15.75 0.25 -10 -15.25 0.25 -10
3 8 14 1 -10 15 1.5 -10 15.75 0.25 -10
4 8 15.75 0.25 -10 15 1.5 -10 15.5 5 -10 16.5 5.75 -10
4 16 16.5 5.75 -10 18 6 -10 18 0 -10 15.75 0.25 -10
4 16 -16 5.75 -10 -18 6 -10 18 6 -10 16.5 5.75 -10
4 16 -15.25 0.25 -10 -18 0 -10 -18 6 -10 -16 5.75 -10
4 16 15.75 0.25 -10 18 0 -10 -18 0 -10 -15.25 0.25 -10
Status:
Official
This part has the following errors
- Pattern parts and sticker shortcuts must have a "Set <setnumber>", "CMF", or "Build-A-Minifigure" keyword
