0 ~Minifig Leg Right with Reflective Stripe Pattern (Obsolete)
0 Name: 3816bp8h.dat
0 Author: Chris Dee [cwdee]
0 !LDRAW_ORG Part UPDATE 2023-03
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !CATEGORY Obsolete
0 !KEYWORDS Emmet, Set 70818
0 !CMDLINE -c25
0 !HISTORY 2015-10-27 [Christophe_Mitillo] Original pattern design
0 !HISTORY 2020-06-13 [cwdee] Adapted to corrected geometry
0 !HISTORY 2020-09-05 [PTadmin] Official Update 2020-02
0 !HISTORY 2023-05-21 [Holly-Wood] Obsoleted due to bad geometry
0 !HISTORY 2023-06-24 [OrionP] Official Update 2023-03
1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\3817bs01.dat
0 // Curve
1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\3817bs03.dat
0 // Front pattern
4 80 -18.3 15.609 -4 -2.05 15.609 -4 -2.05 10.659 -4 -18.3 10.659 -4
4 16 -1.5 20 -4 -1.5 7.657 -4 -2 7.657 -4 -2.05 10.659 -4
3 16 -2.05 15.609 -4 -1.5 20 -4 -2.05 10.659 -4
4 16 -19.23 20 -4 -1.5 20 -4 -2.05 15.609 -4 -18.3 15.609 -4
4 16 -18.3 15.609 -4 -18.3 10.659 -4 -18.804 7.399 -4 -19.23 20 -4
4 16 -2.05 10.659 -4 -2 7.657 -4 -18.804 7.399 -4 -18.3 10.659 -4
3 16 -2 7.657 -4 -2 7.399 -4 -18.804 7.399 -4
