File Detail parts/3831.dat

Download Download zip file View patterns/composites/shortcuts

Official File parts/3831.dat

Part Attributes:

External Sites:

View on Rebrickable View on BrickLink View on Brickset View on BrickOwl

File Header:

0 Hinge Brick  1 x  4 Base
0 Name: 3831.dat
0 Author: James Jessiman
0 !LDRAW_ORG Part UPDATE 2020-03
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 1998-06-20 [PTadmin] Official Update 1998-06
0 !HISTORY 2003-06-08 [jriley] BFC compliant
0 !HISTORY 2003-12-19 [PTadmin] Official Update 2003-03
0 !HISTORY 2007-06-29 [PTadmin] Header formatted for Contributor Agreement
0 !HISTORY 2008-07-01 [PTadmin] Official Update 2008-01
0 !HISTORY 2008-07-07 [guyvivan] Replace 1-4ndis by 1-4ring underside (2005-11-22)
0 !HISTORY 2009-05-02 [PTadmin] Official Update 2009-01
0 !HISTORY 2020-06-04 [Sirio] Updated the use of primitives: removed ringr.dat or ringrr.dat, introduced n-fcylo.dat
0 !HISTORY 2020-12-29 [PTadmin] Official Update 2020-03

Show contents

0 // Primitives
1 16 -20 4 10 1 0 0 0 -5 0 0 0 1 stud3.dat
1 16 -20 0 10 -1 0 0 0 1 0 0 0 -1 stug-1x2.dat
1 16 -4 4 4 -6 0 0 0 -1 0 0 0 6 1-4ndis.dat
1 16 -10 24 10 6 0 0 0 -1 0 0 0 -6 1-4tang.dat
1 16 0 24 0 -8 0 0 0 1 0 0 0 -8 3-4edge.dat
1 16 0 24 0 0 0 2 0 -1 0 2 0 0 3-4ring3.dat
1 16 0 24 0 0 0 -6 0 -1 0 6 0 0 1-4tang.dat
1 16 0 8 0 2 0 0 0 1 0 0 0 2 4-4ring3.dat
1 16 -10 10 10 6 0 0 0 -1 0 0 0 -6 1-4chrd.dat
1 16 -4 10 4 -6 0 0 0 -1 0 0 0 6 1-4chrd.dat
1 16 0 0 0 0 0 -8 0 1 0 8 0 0 1-4ndis.dat
1 16 -24 12 0 0 0 16 12 0 0 0 1 0 rect3.dat
1 16 -23 14 4 -13 0 0 0 0 10 0 -1 0 rect2p.dat
1 16 -4 14 13 0 1 0 0 0 10 -3 0 0 rect2p.dat
1 16 0 12 14 0 -1 0 -12 0 0 0 0 -6 rect3.dat
1 16 -20 12 10 0 0 -20 -12 0 0 0 10 0 box2-5.dat
0 BFC INVERTNEXT
1 16 -20 14 10 0 0 -16 -10 0 0 0 6 0 box2-5.dat
0 BFC INVERTNEXT
1 16 -10 10 10 6 0 0 0 14 0 0 0 -6 1-4cylo.dat
1 16 -4 4 4 -6 0 0 0 6 0 0 0 6 1-4cylo.dat
0 BFC INVERTNEXT
1 16 0 0 0 -8 0 0 0 8 0 0 0 8 1-4cylo.dat
0 BFC INVERTNEXT
1 16 0 8 0 6 0 0 0 16 0 0 0 6 4-4cylo.dat
1 16 0 8 0 -8 0 0 0 16 0 0 0 -8 3-4cylo.dat
0 // Faces
4 16 0 24 8 -4 24 10 -4 24 16 0 24 20
4 16 0 24 20 -4 24 16 -36 24 16 -40 24 20
4 16 -40 24 20 -36 24 16 -36 24 4 -40 24 0
4 16 -40 24 0 -36 24 4 -10 24 4 -8 24 0
4 16 -36 4 16 -10 4 10 -10 4 4 -36 4 4
4 16 -36 4 16 -4 4 16 -4 4 10 -10 4 10
4 16 0 0 20 -40 0 20 -8 0 8 0 0 8
4 16 -40 0 20 -40 0 0 -8 0 0 -8 0 8
4 16 0 24 8 0 24 6 -4 24 8.8066 -4 24 10
4 16 0 24 6 -1.1934 24 6 -4.4566 24 7.7038 -4 24 8.8066
4 16 -1.1934 24 6 -2.2962 24 5.5434 -4.9132 24 6.601 -4.4566 24 7.7038
4 16 -2.2962 24 5.5434 -3.399 24 5.0868 -5.7574 24 5.7574 -4.9132 24 6.601
4 16 -3.399 24 5.0868 -4.2426 24 4.2426 -6.601 24 4.9132 -5.7574 24 5.7574
4 16 -4.2426 24 4.2426 -5.0868 24 3.399 -7.7038 24 4.4566 -6.601 24 4.9132
4 16 -5.0868 24 3.399 -5.5434 24 2.2962 -8.8066 24 4 -7.7038 24 4.4566
4 16 -5.5434 24 2.2962 -6 24 1.1934 -10 24 4 -8.8066 24 4
4 16 -6 24 1.1934 -6 24 0 -8 24 0 -10 24 4
0 // Edges
2 24 -4 4 10 -4 10 10
2 24 -10 4 4 -10 10 4

Status:

Official

Unofficial parents

Part Events:

Archived Part Events:

None

Creative Commons Attribution License information

This part is copyright © James Jessiman
Licensed under CC BY 4.0

Edits:
LDraw.org Parts Tracker, John Riley, Guy Vivan, Massimo Maso,
