Official File parts/47757.dat
Part Attributes:
File Header:
0 Wedge 4 x 4 Quadruple Convex Slope Center
0 Name: 47757.dat
0 Author: Tim Gould [timgould]
0 !LDRAW_ORG Part UPDATE 2010-03
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2008-03-12 [timgould] Created based on 48933 primitive
0 !HISTORY 2008-03-15 [Philo] Added condlines on 2 faces
0 !HISTORY 2010-12-31 [PTadmin] Official Update 2010-03
Show contents
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\48933s01.dat
0 // Top surface
4 16 -20 0 -10 -2 -8 -30 2 -8 -30 20 0 -10
4 16 20 20 -70 2 -8 -30 -2 -8 -30 -20 20 -70
2 24 -20 0 -10 -2 -8 -30
2 24 20 0 -10 2 -8 -30
2 24 -2 -8 -30 2 -8 -30
2 24 -20 20 -70 -2 -8 -30
2 24 20 20 -70 2 -8 -30
0 // Side 1
4 16 20 0 -10 40 20 -10 40 20 10 20 0 10
2 24 20 0 -10 40 20 -10
3 16 20 20 -70 34.6 17.6 -16 14.6 -2.4 -16
3 16 14.6 -2.4 -16 2 -8 -30 20 20 -70
4 16 40 20 -10 20 0 -10 14.6 -2.4 -16 34.6 17.6 -16
3 16 20 20 -70 40 20 -10 34.6 17.6 -16
2 24 14.6 -2.4 -16 34.6 17.6 -16
2 24 34.6 17.6 -16 40 20 -10
2 24 34.6 17.6 -16 20 20 -70
5 24 14.6 -2.4 -16 20 20 -70 34.6 17.6 -16 2 -8 -30
0 // Side 2
4 16 -20 0 -10 -20 0 10 -40 20 10 -40 20 -10
2 24 -20 0 -10 -40 20 -10
3 16 -20 20 -70 -2 -8 -30 -14.6 -2.4 -16
3 16 -14.6 -2.4 -16 -34.6 17.6 -16 -20 20 -70
4 16 -40 20 -10 -34.6 17.6 -16 -14.6 -2.4 -16 -20 0 -10
3 16 -20 20 -70 -34.6 17.6 -16 -40 20 -10
2 24 -14.6 -2.4 -16 -34.6 17.6 -16
2 24 -34.6 17.6 -16 -40 20 -10
2 24 -34.6 17.6 -16 -20 20 -70
5 24 -14.6 -2.4 -16 -20 20 -70 -34.6 17.6 -16 -2 -8 -30
