Cockpit 4 x 2 x 3 with Pinhole and Clips

File Header:

0 Cockpit  4 x  2 x  3 with Pinhole and Clips
0 Name: 98876.dat
0 Author: Jeff Jones [notmaster]
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !KEYWORDS battle suit, body, DC, Marvel, mech, Ninjago, Superheroes

0 !HISTORY 2024-09-30 [notmaster] modified from 27168.dat
