Unofficial File parts/6826.dat
Part Attributes:
File Header:
0 Brick 2 x 2 with Rounded Bottom
0 Name: 6826.dat
0 Author: Gerald Lasser [GeraldLasser]
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
Show contents
1 16 0 4 10 0 0 -1 0 -5 0 1 0 0 stud3.dat
0 BFC INVERTNEXT
1 16 0 24 10 0 0 -16 0 -20 0 6 0 0 box5.dat
1 16 0 4 14 0 0 -1 0 16 0 -1 0 0 boxjcyl4.dat
1 16 0 4 6 0 0 -1 0 16 0 1 0 0 boxjcyl4.dat
1 16 0 4 5 0 0 -1 0 16 0 1 0 0 box3u5p.dat
1 16 0 4 15 0 0 -1 0 16 0 -1 0 0 box3u5p.dat
4 16 20 24 0 16 24 4 16 24 16 20 24 20
4 16 -20 24 20 -16 24 16 -16 24 4 -20 24 0
2 24 20 24 20 20 24 0
2 24 -20 24 0 -20 24 20
0 // Outside
4 16 -4 24 0 -16 24 4 16 24 4 4 24 0
1 16 4 4 0 0 -8 0 0 0 20 -20 0 0 48\1-4cyli.dat
4 16 -4 4 -20 4 4 -20 20 0 -20 -20 0 -20
4 16 16 24 16 -16 24 16 -20 24 20 20 24 20
0 // Inside
0 BFC INVERTNEXT
1 16 -17 4 0 0 34 0 0 0 17 -17 0 0 1-8cyli.dat
1 16 0 0 20 0 0 -1 0 1 0 1 0 0 s\5174s02.dat
1 16 0 0 20 0 0 1 0 1 0 1 0 0 s\5174s02.dat
4 16 20 0 -20 8.5 0 -17 -8.5 0 -17 -20 0 -20
4 16 -8.5 0 -17 8.5 0 -17 8.5 4 -17 -8.5 4 -17
2 24 -8.5 0 -17 8.5 0 -17
4 16 4.4018 16.0207 -12.0207 2.3727 17.3712 -10 -2.3727 17.3712 -10 -4.4018 16.0207 -12.0207
4 16 .2312 19.8161 -5.9535 -.2312 19.8161 -5.9535 -2.3727 17.3712 -10 2.3727 17.3712 -10
4 16 -.2312 19.8161 -5.9535 .2312 19.8161 -5.9535 1.8238 20.6373 -1.8238 -1.8238 20.6373 -1.8238
4 16 1.8238 20.6373 -1.8238 3.7814 21 0 -3.7814 21 0 -1.8238 20.6373 -1.8238
4 16 8.5 19.5877 0 8.5 0 0 -8.5 0 0 -8.5 19.5877 0
4 16 8.5 19.5877 0 -8.5 19.5877 0 -5.8578 20.0238 0 5.8578 20.0238 0
4 16 3.7814 21 0 5.8578 20.0238 0 -5.8578 20.0238 0 -3.7814 21 0
2 24 -3.7814 21 0 3.7814 21 0
2 24 -8.5 0 0 8.5 0 0
2 24 -20 0 20 20 0 20
5 24 2.3727 17.3712 -10 -2.3727 17.3712 -10 -4.4018 16.0207 -12.0207 .2312 19.8161 -5.9535
5 24 -.2312 19.8161 -5.9535 .2312 19.8161 -5.9535 1.8238 20.6373 -1.8238 -2.3727 17.3712 -10
0 // Top
3 16 -20 0 -20 -17 0 0 -20 0 20
3 16 -20 0 20 -17 0 0 -11.5 0 0
3 16 -11.5 0 0 -8.5 0 0 -20 0 20
4 16 20 0 20 -20 0 20 -8.5 0 0 8.5 0 0
3 16 20 0 20 8.5 0 0 11.5 0 0
3 16 17 0 0 20 0 20 11.5 0 0
3 16 20 0 20 17 0 0 20 0 -20
1 16 0 0 10 0 0 -1 0 1 0 1 0 0 stug-2x1.dat
1 16 0 0 0 0 0 -20 0 1 0 20 0 0 recte4.dat
1 16 10 0 -10 0 0 -1 0 1 0 1 0 0 stud2a.dat
1 16 -10 0 -10 0 0 -1 0 1 0 1 0 0 stud2a.dat
0 // Outside
1 16 -20 4 0 0 1 0 0 0 20 -20 0 0 48\1-4chrd.dat
4 16 -20 0 20 -20 24 20 -20 24 0 -20 4 -20
3 16 -20 0 20 -20 4 -20 -20 0 -20
1 16 20 4 0 0 -1 0 0 0 20 -20 0 0 48\1-4chrd.dat
4 16 20 24 0 20 24 20 20 0 20 20 4 -20
3 16 20 4 -20 20 0 20 20 0 -20
1 16 0 12 20 20 0 0 0 0 12 0 -1 0 rect3.dat
Status:
Errors Found (HN)
This part has the following warnings
- Number in description may need a leading space
This part has the following automated holds from the Parts Tracker
-
Has Uncertified Subfiles
Current Votes:
| User | Vote |
|---|---|
| Blechtaler | Hold |
Official parents and subparts
Part Events:
Gerald Lasser [GeraldLasser]
initially submitted the part.
2025-01-04 22:17:36
Gerald Lasser [GeraldLasser]
made the following comment.
2025-01-04 22:20:24
Rene Rechthaler [Blechtaler]
made the following comment.
2025-01-04 22:38:15
yes I think it should be rotated, also matches the other slopes and curved bricks then...
Philippe Hurbain [Philo]
made the following comment.
2025-01-05 07:40:30
1750 orientation for me!
Magnus Forsberg [MagFors]
posted a vote of Hold
2025-01-05 16:21:42
Duplicated surfaces at the botton pin.
Gerald Lasser [GeraldLasser]
submitted a new version of the part (all votes reset).
2025-01-23 09:48:55
changed orientation
be aware that this underside is different from 1750 as it has stud cut outs
Duplicate surfaces removed
be aware that this underside is different from 1750 as it has stud cut outs
Duplicate surfaces removed
Rene Rechthaler [Blechtaler]
posted a vote of Hold
2025-04-10 16:22:50
outside curvature should be standard res like 1750
Gerald Lasser [GeraldLasser]
made the following comment.
2025-04-22 11:26:00
@Rene, contrary to 1750, whihc works well with Prim-Substitution, this does not.
It has stud cut outs, this will not work good when primitve substitution is applied. Furthermore radius is large at 20 LDU
It has stud cut outs, this will not work good when primitve substitution is applied. Furthermore radius is large at 20 LDU
Creative Commons Attribution License information
This part is copyright ©
Gerald Lasser
Licensed under
CC BY 4.0
or should it follow 1750?
https://library.ldraw.org/parts/1160
