0 ~Duplo Tipper Bucket Bed - Lip Section
0 Name: s\14094s02.dat
0 Author: Peter Blomberg [WUIt]
0 !LDRAW_ORG Unofficial_Subpart
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
Show contents
0 BFC INVERTNEXT
1 16 79 -39.25 -20.5 -1 0 0 0 0 -44.25 0 -16.5 0 box2-5.dat
