Unofficial File parts/3096-f1.dat
Part Attributes:
File Header:
0 Technic Tread Crawler
0 Name: 3096-f1.dat
0 Author: Michael Heidemann [mikeheide]
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !KEYWORDS Bricklink x486, Rebrickable 498, Vehicle
0 !HISTORY 2010-07-05 [PTadmin] Official Update 2010-02
0 !HISTORY 2022-07-18 [PTadmin] Moved from 498
0 !HISTORY 2022-07-19 [SwampKryakwa] Now built using flexible sections
Show contents
1 16 -6.5 0 0 1 0 0 0 1 0 0 0 1 3096k01.dat
1 16 -19.5 0 0 1 0 0 0 1 0 0 0 1 3096k01.dat
1 16 -32.5 0 0 1 0 0 0 1 0 0 0 1 3096k01.dat
1 16 -45.5 0 0 1 0 0 0 1 0 0 0 1 3096k01.dat
1 16 -58.5 0 0 1 0 0 0 1 0 0 0 1 3096k03.dat
1 16 -60 0 0 .832 .556 0 -.556 .832 0 0 0 1 3096k02.dat
1 16 -60 0 0 .556 .832 0 -.832 .556 0 0 0 1 3096k02.dat
1 16 -60 0 0 .195 .981 0 -.981 .195 0 0 0 1 3096k02.dat
1 16 -60 0 0 .981 .195 0 -.195 .981 0 0 0 1 3096k02.dat
1 16 6.5 0 0 1 0 0 0 1 0 0 0 1 3096k01.dat
1 16 19.5 0 0 1 0 0 0 1 0 0 0 1 3096k01.dat
1 16 32.5 0 0 1 0 0 0 1 0 0 0 1 3096k01.dat
1 16 45.5 0 0 1 0 0 0 1 0 0 0 1 3096k01.dat
1 16 58.5 0 0 -1 0 0 0 1 0 0 0 1 3096k03.dat
1 16 60 0 0 -.981 -.195 0 -.195 .981 0 0 0 1 3096k02.dat
1 16 60 0 0 -.832 -.556 0 -.556 .832 0 0 0 1 3096k02.dat
1 16 60 0 0 -.556 -.832 0 -.832 .556 0 0 0 1 3096k02.dat
1 16 -6.5 0 0 1 0 0 0 -1 0 0 0 1 3096k01.dat
1 16 -19.5 0 0 1 0 0 0 -1 0 0 0 1 3096k01.dat
1 16 -32.5 0 0 1 0 0 0 -1 0 0 0 1 3096k01.dat
1 16 -45.5 0 0 1 0 0 0 -1 0 0 0 1 3096k01.dat
1 16 -58.5 0 0 1 0 0 0 -1 0 0 0 1 3096k03.dat
1 16 -60 0 0 .981 .195 0 .195 -.981 0 0 0 1 3096k02.dat
1 16 -60 0 0 .832 .556 0 .556 -.832 0 0 0 1 3096k02.dat
1 16 -60 0 0 .556 .832 0 .832 -.556 0 0 0 1 3096k02.dat
1 16 6.5 0 0 1 0 0 0 -1 0 0 0 1 3096k01.dat
1 16 19.5 0 0 1 0 0 0 -1 0 0 0 1 3096k01.dat
1 16 32.5 0 0 1 0 0 0 -1 0 0 0 1 3096k01.dat
1 16 45.5 0 0 1 0 0 0 -1 0 0 0 1 3096k01.dat
1 16 58.5 0 0 -1 0 0 0 -1 0 0 0 1 3096k03.dat
1 16 60 0 0 -.832 -.556 0 .556 -.832 0 0 0 1 3096k02.dat
1 16 60 0 0 -.556 -.832 0 .832 -.556 0 0 0 1 3096k02.dat
1 16 60 0 0 -.195 -.981 0 .981 -.195 0 0 0 1 3096k02.dat
1 16 60 0 0 -.981 -.195 0 .195 -.981 0 0 0 1 3096k02.dat
0 //
Status:
Errors Found (HN)
This part has the following automated holds from the Parts Tracker
Current Votes:
| User | Vote |
|---|---|
| Blechtaler | Hold |
Official parents and subparts
Part Events:
[PTadmin]
renamed the part.
2022-07-19 04:55:03
"parts/498.dat" to "parts/3096.dat."
[PTadmin]
edited the part header.
2022-07-19 05:00:01
2022-07-19 05:00:06
While this is fine as is, if some motivated individual wants to split this into flexible sections I'd be appreciative
Separated into segments
Existing certification-votes were deleted.
Existing certification-votes were deleted.
2022-07-19 06:35:01
Oh. I just realized that I messed it a veeeeeeeeery little bit. Gotta fix it soon
Yes, you need to create Flexible Sections, not subfiles.
Fixed losing few segments
What an exact difference between flexible segments and subfiles is, I don't understand?
Existing certification-votes were deleted.
What an exact difference between flexible segments and subfiles is, I don't understand?
Existing certification-votes were deleted.
Third time's a charm I guess? Somehow added one extra segment. Note to myself - never ever touch LDraw again without having a good sleep same day
Is now properly built using segmented sections, need to have it's number changed accordingly (into 3096-f1) and probably renamed
Hold pending renumber
[PTadmin]
renamed the part.
2022-07-19 14:40:42
"parts/3096.dat" to "parts/3096-f1.dat."
2022-07-19 14:45:02
2022-07-19 16:00:01
now it seems that there are a bit too much treads, Bricklink says 30...
seems to be a newer version of 486, maybe copy the design from there.
Bricklink also lists this part as a version of x486a named x486, maybe include this other part number in the header.
seems to be a newer version of 486, maybe copy the design from there.
Bricklink also lists this part as a version of x486a named x486, maybe include this other part number in the header.
2022-07-19 16:15:02
x486a was just released as 486. 3096 is the number for the "earlier" of the 2 variants, this one. I couldn't confirm that 486 was also 3096 as a mold variant so I left it as 486 (it probably is but probably isn't good enough for numbering).
2022-07-19 16:50:01
Actually, 3096 is the newer.
x486a = 1969-1970
x486 = 3096 = 1969-1987
You renamed the right one, I just wanted to make it clear that 3096 is the newer, or at least more long-lived, tread.
x486a = 1969-1970
x486 = 3096 = 1969-1987
You renamed the right one, I just wanted to make it clear that 3096 is the newer, or at least more long-lived, tread.
2022-07-20 21:50:01
Probably rename this to "Caterpillar Track 1.8 Wide with 30 Ridges (Formed for 2 Wheel Rim)"?
2022-07-20 22:05:01
Also needs "0 !CATEGORY Vehicle, Bricklink x486".
This one is for sure newer, since only appearance before 1971 are all alternates. Likely was introduced in re-releases as replacement for x486a and was used after that.
This one is for sure newer, since only appearance before 1971 are all alternates. Likely was introduced in re-releases as replacement for x486a and was used after that.
Tweaked a bit to avoid gaps between curved segments
Existing certification-votes were deleted.
Existing certification-votes were deleted.
[PTadmin]
edited the part header.
2022-07-21 01:00:01
2023-01-03 14:05:01
Just found that part and can confirm its wrong: there are only 5 segments at round part...
If there are tread parts at the outer middle:
__________
(__________) <-- tread segment at the outermost position
then there are 10 segments straight and 5 around the rim...
If there are tread parts at the outer middle:
__________
(__________) <-- tread segment at the outermost position
then there are 10 segments straight and 5 around the rim...
2024-01-04 21:41:10
2025-07-28 16:08:50
bump
Creative Commons Attribution License information
This part is copyright © Michael Heidemann
Licensed under CC BY 4.0
Edits:
LDraw.org Parts Tracker,
Max Murtazin,
3D View
Website copyright ©2003-2025 LDraw.org, see Legal Info for details.
