Unofficial File parts/u9226b.dat
Warning: Model breaking changes to unofficial parts may occur anytime prior to release
~Train Track 12V Tapered Point Vertical Axle Electric
0 ~Train Track 12V Tapered Point Vertical Axle Electric
0 Name: u9226b.dat
0 Author: Rene Rechthaler [Blechtaler]
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !CATEGORY Train
Show file code:
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\u9226s01.dat
1 16 0 0 0 0 0 1 0 1 0 1 0 0 s\u9226bs01.dat
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\u9226bs01.dat
1 16 0 0 0 1 0 0 0 1 0 0 0 -1 s\u9226bs01.dat
1 16 0 0 0 0 0 1 0 1 0 -1 0 0 s\u9226bs01.dat
1 16 0 0 0 0 0 -1 0 1 0 -1 0 0 s\u9226bs01.dat
1 16 0 0 0 -1 0 0 0 1 0 0 0 -1 s\u9226bs01.dat
1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\u9226bs01.dat
1 16 0 0 0 0 0 -1 0 1 0 1 0 0 s\u9226bs01.dat
2 24 0 16 15 0 25 15
2 24 10.6065 16 10.6065 10.6065 25 10.6065
2 24 15 16 0 15 25 0
2 24 10.6065 16 -10.6065 10.6065 25 -10.6065
2 24 0 16 -15 0 25 -15
2 24 -10.6065 16 -10.6065 -10.6065 25 -10.6065
2 24 -15 16 0 -15 25 0
2 24 -10.6065 16 10.6065 -10.6065 25 10.6065

Status

Not releaseable Needs 1 More Vote (CN) Needs 1 More Vote (CN)

Current Votes:

Certify
Takeshi Takahashi [RainbowDolphin]
This part has the following automated holds from the Parts Tracker

Part Dependencies

Official parents and subparts

Part Events

Rene Rechthaler [Blechtaler]
Part Header Editor
initially submitted the part.
2024-03-02 15:12:16
Rene Rechthaler [Blechtaler]
Part Header Editor
made the following comment.
2024-03-02 15:18:32
this part isnt geometrically perfect, the upper ring should have 23 instead of 24 teeth and the lower one 7.8 instead of 8 teeth.
also the teeth are straight, should be curved.
Takeshi Takahashi [RainbowDolphin]
Senior Part Reviewer
posted a vote of Certify
2024-05-31 15:24:52
